Physical Characteristics |
Dimensions | 6 in. H x 2.5 in. W x 3.34 in. D 15.2 cm H x 6.3 cm W x 8.4 cm |
Weight | 5.29 oz/150 gm |
Voltage & Current: | 5 volts +/- 10% at 130 mA typical, 175 mA max |
Color | Cash Register White or Twilight Black |
Power Source: | Host power or external power supply |
User Environment | |
Beeper Volume: | User-selectable: three levels |
Operating Temp. | 32° to 122° F/0° to 50° C |
Humidity | 5% to 95% relative humidity, non-condensing |
Storage Temp. | -40° to 158° F/-40° to 70° C |
Humidity | 5% to 95% non-condensing |
Drop Specification | Unit functions normally after repeated 5 ft./1.5 m drops to concrete |
Electrostatic Discharge: | Conforms to 15 kV air discharge and 8 kV of contact discharge |
ESD | Conforms to 15 kV air discharge and 8 kV of contact discharge |
Ambient Lighting Tolerance | Tolerant to typical artificial indoor and Tolerance: natural outdoor ( direct sunlight) lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED : 450 Ft Candles (4,844 Lux) Sunlight: 8000 Ft Candles (86,111 Lux) |
Performance Characteristics |
Scanner Type: | Bi-directional |
Light Source: | Microsoft® Windows CE 5.0 |
Scan Element Frequency: | 64MB/64MB |
Scan Rate: | Microsoft Windows client CE EMDK; Zebra EMDK; MCL Designer V 3.0 (MCL Client pre-loaded on both the MT2070 and the MT2090; pre-licensed on the MT2070 only) |
Print Contrast: | 20% minimum reflective difference |
Decode Capability: | UPC/EAN, UPC/EAN with Supplementals, UPC/ EAN 128, Code 39, Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128 Full ASCII, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, IATA, GS1 DataBar (formerly RSS) variants, Chinese 2 of 5 |
Interfaces Supported: | USB, RS232, Keyboard Wedge, IBM 468x/9x |
REGULATORY |
Electrical Safety | Certified to UL1950, CSA C22.2 No. 950, EN60950/IEC950 |
Laser Safety | CDRH Class II, IEC Class 2 |
EMI/RFI | FCC Part 15 Class B, ICES-003 Class B, European Union EMC Directive, Australian SMA, Taiwan EMC, Japan VCCI/MITI/Dentori. |
Environmental: | Compliant with RoHS directive 2002/95/EEC |
