Morris 11970 Red Nylon Insulated Double Crimp F Disconnect, (Pack of 100 pcs)

Morris, 11970, 22-16 AWG 0.032mm x 0.250mm Red Nylon Insulated Double Crimp F Disconnect

Features:

• Double Crimp Fully Insulated Female Disconnects feature Nylon Insulation
• Color Coded insulation for easy identification
• Manufactured from High Strength Brass
• Electro-Tin Plated for corrosion resistance
• Easy Entry Expanded Insulation eliminates strand “Hang Up”, increasing crimping rates and provides mechanical strain relief
• Terminal Barrel has Butted Seam
• Serrated Barrel provides excellent electrical contact & resistance to pull-out forces
• Double Crimp Extended Crimp Sleeve provides for multiple crimps resulting in improved electrical contact and pull-out force resistance
• 221°F (105°C) 600 Volts Max
• Maximum Electric Current: 22 AWG - 3 Amp, 20 AWG - 4 Amp, 18 AWG - 7 Amp, 16 AWG - 10 Amp, 14 AWG - 15 Amp, 12 AWG - 20 Amp, 10 AWG - 24 Amp
• cULus Listed
• Dimension Measurements = Inches
• Order Qty of 100 = 1 Bag of 100
