Application:

Quick check of diameter of cylindrical parts (shafts, bolts, shanks)
Thickness and length measurements
Particularly suitable for exact series components

Features:

Operating and display units with satin chrome finish
Rugged steel frame, can be inclined up to 45° from the sturdy base
Retraction of the movable anvil ensures maximum wear resistance
Height adjustable stop
Constant measuring force
Stainless spindle is hardened throughout and ground
Spindle and anvil are carbide-tipped
Locking device

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Optional Accessories

Measuring range	0 - 50
Readings ( µm)	1 µm
Error limit µm	2 µm
Error limit Ge ( µm)	1 µm
Parallel error in µm	2 µm
Flatness in µm	0.2 µm
Spindle diameter	7.5 mm
Spindle thread pitch	0.5 mm
Dial color	Yellow
Type of dial face	50-0-50

Product Details

Measuring range	0 - 50
Readings ( µm)	1 µm
Error limit µm	2 µm
Error limit Ge ( µm)	1 µm
Parallel error in µm	2 µm
Flatness in µm	0.2 µm
Spindle diameter	7.5 mm
Spindle thread pitch	0.5 mm
Dial color	Yellow
Type of dial face	50-0-50
