| Application | Wire Reducing Splice |
| Color Code | Blue, Gray |
| Color Code - Side A | Blue |
| Color Code - Side B | Blue |
| Connector Type | STANDARD BARREL KITS |
| Die Index | 19/7 |
| Die Index - Element A | 19;L80 |
| Die Index - Element B | 7 |
| Die Index Run Side | 19;L80 |
| Die Index Tap Side | 7 |
| Feature - Barrel Style | Skived |
| Feature - Barrel Type | Standard |
| Finish Type | Tin-Plated |
| Material | COPPER |
| Plated | Y |
| Plating Type | Tin - Electro Plated |
| Temperature Rating | 194 |
| Trade Name | HYREDUCER™ |
| Dimension - B Length fraction | 1-11/16 in |
| Dimension - B Length inch | 1.69 in |
| Dimension - L Length Overall mm | 108 mm |
| Dimension - Length BB inch | 0.73 in |
| Dimension - Length Overall inch | 4.26 in |
| Dimension - Strip Length inch | 1.60 in |
| Rating - KVA | 35 kV |
| Voltage - Maximum | 35000 |
| Voltage Rating | 35 kV |
| Conductor - Copper Flex G Run | 350 KCMIL |
| Conductor - Copper Flex G Size A | 350 kcmil |
| Conductor - Copper Flex G Size A Range | 350 kcmil |
| Conductor - Copper Flex G Size B Range | 6 AWG |
| Conductor - Copper Flex G Tap | 6 AWG |
| Conductor - Copper Flex H Run | 350 KCMIL |
| Conductor - Copper Flex H Size A | 350 kcmil |
| Conductor - Copper Flex H Size A Range | 350 kcmil |
| Conductor - Copper Flex H Size B Range | 6 AWG |
| Conductor - Copper Flex H Tap | 6 AWG |
| Conductor - Copper Flex I Run | 350 KCMIL |
| Conductor - Copper Flex I Size A | 350 kcmil |
| Conductor - Copper Flex I Size A Range | 350 kcmil |
| Conductor - Copper Flex I Size B | 6 AWG |
| Conductor - Copper Flex I Size B Range | 6 AWG |
| Conductor - Copper Flex I Tap | 6 AWG |
| Conductor - Copper Flex K Run | 350 KCMIL |
| Conductor - Copper Flex K Size A | 350 kcmil |
| Conductor - Copper Flex K Size A Range | 350 kcmil |
| Conductor - Copper Flex K Size B | 6 AWG |
| Conductor - Copper Flex K Size B Range | 6 AWG |
| Conductor - Copper Flex K Tap | 6 AWG |
| Conductor - Copper Flex M Run | 350 KCMIL |
| Conductor - Copper Flex M Size A | 350 kcmil |
| Conductor - Copper Flex M Size A Range | 350 kcmil |
| Conductor - Copper Flex M Size B | 6 AWG |
| Conductor - Copper Flex M Size B Range | 6 AWG |
| Conductor - Copper Flex M Tap | 6 AWG |
| Conductor - Copper Str Size | 350 KCMIL-6 AWG |
| Conductor - Copper Str Size B | 6 AWG |
| Conductor - Material | COPPER |
| Conductor Size | 350 KCMIL-6 AWG |
| Conductor Type | CODE/FLEX |
| Wire Size | 350 KCMIL-6 AWG |
| Certification - CSA Approved | No |
| Certification - ETL | No |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Standards - RoHS Compliance Status | CM |
| UL Listed | No |
