Buy Burndy YHO125, Compression Line H Tap, (Pack of 50 pcs)

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Package Quantity: Pack of 50 pcs

Options and Related Products

Range:: Range: 0.162" - 0.398" Run / 0.162" - 0.332" Tap

Burndy, YHO125, Compression Line H Tap, 0.162" - 0.398" Run / 0.162" - 0.332" Tap

See more product information See less

Return and Warranty

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Resources

Reviews

Die Index	O
Material	Aluminum
Plated	N
Plating Type	Unplated
Prefilled Oxide Inhibitor	Y
Dimension - Height fraction	1-3/20 in
Dimension - Height inch	1.15 in
Dimension - L Length Overall mm	41 mm
Dimension - Length Overall inch	1.62 in
Dimension - Width fraction	7/10 in
Dimension - Width inch	0.70 in
Dimension - Width mm	18 mm
Conductor - ACSR Cmpt Run	6 AWG; 4 AWG; 3 AWG; 2 AWG; 1 AWG; 1/0 AWG
Conductor - ACSR Cmpt Run Range	6 AWG-1/0 AWG
Conductor - ACSR Cmpt Tap	6 AWG; 4 AWG; 3 AWG; 2 AWG; 1 AWG
Conductor - ACSR Cmpt Tap Range	6 AWG-1 AWG
Conductor - ACSR Str Run	6 (6/1) Turkey AWG; 5 (6/1) Thrush AWG; 4 (6/1) Swan AWG; 4 (7/1) Swanate AWG; 3 (6/1) Swallow AWG; 2 (6/1) Sparrow AWG; 2 (7/1) Sparate AWG; 1 (6/1) Robin AWG; 1/0 (6/1) Raven AWG
Conductor - ACSR Str Run Range	6 (6/1) Turkey AWG-1/0 (6/1) Raven AWG
Conductor - ACSR Str Tap	6 (6/1) Turkey AWG; 5 (6/1) Thrush AWG; 4 (6/1) Swan AWG; 4 (7/1) Swanate AWG; 3 (6/1) Swallow AWG; 2 (6/1) Sparrow AWG; 2 (7/1) Sparate AWG
Conductor - ACSR Str Tap Range	6 (6/1) Turkey AWG-2 (7/1) Sparate AWG
Conductor - AL Str Run	#6 - 1/0
Conductor - AL Str Run Range	#6 - 1/0
Conductor - AL Str Tap	6 AWG; 4 AWG; 3 AWG; 2 AWG; 1 AWG
Conductor - AL Str Tap Range	6 AWG-1 AWG
Conductor - Copper Solid Run	6 AWG; 5 AWG; 4 AWG; 3 AWG; 2 AWG; 1 AWG; 1/0 AWG; 2/0 AWG
Conductor - Copper Solid Run Range	6 AWG-2/0 AWG
Conductor - Copper Solid Tap	6 AWG; 5 AWG; 4 AWG; 3 AWG; 2 AWG; 1 AWG; 1/0 AWG
Conductor - Copper Solid Tap Range	6 AWG-1/0 AWG
Conductor - Copper Str Run	6 AWG; 5 AWG; 4 AWG; 3 AWG; 2 AWG; 1 AWG; 1/0
Conductor - Copper Str Run Range	6 AWG-1/0
Conductor - Copper Str Tap	6 AWG; 5 AWG; 4 AWG; 3 AWG; 2 AWG; 1 AWG
Conductor - Copper Str Tap Range	6 AWG-1 AWG
Certification - CSA Approved	No
Certification - ETL	No
Certification - UL Recognized	No
Certification - cULus	No
Standards - RoHS Compliance Status	CM
UL Listed	No

Notes
