| Color Code | Blue |
| Connector Type | Terminal |
| Die Index | 7;374 |
| Feature - Barrel Style | |
| Feature - Barrel Type | Standard |
| Material | Copper |
| Physical Attribute - Number of Holes | 2 |
| Physical Attribute - Tongue Type | Standard |
| Plated | Y |
| Plating Type | Tin - Electro Plated |
| Type | Standard Barrel, Tin Plated |
| UPC | 781810080504 |
| UPC 12 Digit | 7818100805044 |
| Dimension - B Length fraction | 1/2 in |
| Dimension - B Length inch | 0.50 in |
| Dimension - Bolt Hole Size inch | 0.40 in |
| Dimension - Hole Size inch | 0.40 in |
| Dimension - Hole Size mm | 10 mm |
| Dimension - L Length Overall mm | 65 mm |
| Dimension - Length Overall inch | 2.56 in |
| Dimension - N inch | 0.41 in |
| Dimension - Outside Diameter inch | 0.31 in |
| Dimension - Pad Width inch | 0.58 in |
| Dimension - Strip Length inch | 9/16 in |
| Dimension - Z inch | 0.43 in |
| Physical Attribute - Tongue Angle | 45 Degree |
| Rating - KVA | 35 kV |
| Rating - Minimum Voltage | 600 |
| Voltage - Maximum | 35000 |
| Conductor - Copper DLO Size | 6 (61/24) DLO |
| Conductor - Copper DLO Size Range | 6 AWG |
| Conductor - Copper Flex G Size | 6 AWG |
| Conductor - Copper Flex G Size Range | 6 AWG |
| Conductor - Copper Flex H Size | 6 AWG |
| Conductor - Copper Flex H Size Range | 6 AWG |
| Conductor - Copper Flex I Size | 6 AWG |
| Conductor - Copper Flex I Size Range | 6 AWG |
| Conductor - Copper Flex K Size | 6 AWG |
| Conductor - Copper Flex K Size Range | 6 AWG |
| Conductor - Copper Flex M Size | 6 AWG |
| Conductor - Copper Flex M Size Range | 6 AWG |
| Conductor - Copper Solid Size | 6 AWG |
| Conductor - Copper Solid Size Range | 6 AWG |
| Conductor - Copper Str Navy Size | 30 Navy |
| Conductor - Copper Str Navy Size Range | 30 Navy |
| Conductor - Copper Str Size | 6 AWG |
| Conductor - Copper Str Size Range | 6 AWG |
| Conductor - CopperWeld Str Size | #6 WELD (61/24) |
| Conductor - CopperWeld Str Size Range | #6 WELD (61/24) |
| Conductor - Material | Copper |
| Certification - CSA Approved | Yes |
| Certification - ETL | No |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Industry Standard(s) | UL 486A-486B |
| Standards - RoHS Compliance Status | CM |
| UL Listed | Yes |
