| Color Code | Orange |
| Connector Type | Terminal |
| Die Index | 14 |
| Feature - Barrel Style | Chamfered |
| Feature - Barrel Type | Standard |
| Material | Copper |
| Physical Attribute - Number of Holes | 1 |
| Plated | Y |
| Plating Type | Tin |
| Trade Name | HYLUG™ |
| Type | Standard Barrel, Tin Plated |
| Dimension - B Length fraction | 1 in |
| Dimension - B Length inch | 1.00 in |
| Dimension - Bolt Hole Size inch | 0.52 in |
| Dimension - Bolt Size fraction | 1/2 |
| Dimension - Hole Size inch | 0.53 in |
| Dimension - Hole Size mm | 13 mm |
| Dimension - L Length Overall mm | 63 mm |
| Dimension - Length Overall inch | 2.47 in |
| Dimension - N inch | 0.53 in |
| Dimension - Outside Diameter inch | 0.70 in |
| Dimension - Pad Width inch | 1.03 in |
| Dimension - Strip Length inch | 1 in |
| Dimension - Z inch | 0.55 in |
| Physical Attribute - Tongue Angle | 45 Degree |
| Rating - KVA | 35 kV |
| Rating - Minimum Voltage | 600 |
| Voltage - Maximum | 35000 |
| Conductor - Copper DLO Size | 3/0 (450/#24) DLO |
| Conductor - Copper DLO Size Range | 3/0 AWG |
| Conductor - Copper Flex G Size | 3/0 AWG |
| Conductor - Copper Flex G Size Range | 3/0 AWG |
| Conductor - Copper Flex H Size | 3/0 AWG |
| Conductor - Copper Flex H Size Range | 3/0 AWG |
| Conductor - Copper Flex I Size | 3/0 AWG |
| Conductor - Copper Flex I Size Range | 3/0 AWG |
| Conductor - Copper Flex K Size | 3/0 AWG |
| Conductor - Copper Flex K Size Range | 3/0 AWG |
| Conductor - Copper Flex M Size | 3/0 AWG |
| Conductor - Copper Str Navy Size | 150 (61) Navy |
| Conductor - Copper Str Size | 3/0 AWG |
| Conductor - Copper Str Size Range | 3/0 AWG |
| Conductor - CopperWeld Str Size | 3/0 E AWG; 3/0 EK AWG; 3/0 F AWG; 3/0 G AWG; 3/0 J AWG; 3/0 V AWG |
| Conductor - Material | Copper |
| Certification - CSA Approved | No |
| Certification - ETL | No |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Industry Standard(s) | UL 486A-486B |
| Standards - RoHS Compliance Status | CM |
| UL Listed | No |
