| Application | Wire Termination |
| Color Code | Blue |
| Connector Type | Terminal |
| Die Index | 7374 |
| Feature - Barrel Style | Chamfered |
| Feature - Barrel Type | Standard |
| Finish Type | Nickel Plated |
| Material | Copper |
| Physical Attribute - Number of Holes | 1 |
| Plated | Y |
| Plating Type | Nickel |
| Trade Name | Hylug™ |
| Type | Standard Barrel, Nickel Plated |
| Dimension - B Length fraction | 1/2 in |
| Dimension - B Length inch | .50 In |
| Dimension - Bolt Hole Size inch | 0.27 in |
| Dimension - Hole Size inch | 0.27 in |
| Dimension - Hole Size mm | 7 mm |
| Dimension - L Length Overall mm | 36 mm |
| Dimension - Length Overall inch | 1.43 in |
| Dimension - N inch | 0.31 in |
| Dimension - Outside Diameter inch | .31 in |
| Dimension - Pad Width inch | .48 in |
| Dimension - Strip Length inch | 1/2 in |
| Dimension - Stud Size inch | 1/4 in |
| Dimension - Z inch | 0.33 in |
| Physical Attribute - Tongue Angle | Straight |
| Rating - KVA | 35 kV |
| Voltage - Maximum | 35000 |
| Voltage Rating | 35 kV |
| Conductor - Copper DLO Size | 6(61/#24) DLO |
| Conductor - Copper DLO Size Range | 6 AWG |
| Conductor - Copper Flex G Size | 6 AWG |
| Conductor - Copper Flex G Size Range | 6 AWG |
| Conductor - Copper Flex H Size | 6 AWG |
| Conductor - Copper Flex H Size Range | 6 AWG |
| Conductor - Copper Flex I Size | 6 AWG |
| Conductor - Copper Flex I Size Range | 6 AWG |
| Conductor - Copper Flex K Size | 6 AWG |
| Conductor - Copper Flex K Size Range | 6 AWG |
| Conductor - Copper Flex M Size | 6 AWG |
| Conductor - Copper Flex M Size Range | 6 AWG |
| Conductor - Copper Str Navy Size | 30 |
| Conductor - Copper Str Size | 6 AWG |
| Conductor - Copper Str Size Range | 6 AWG |
| Conductor - CopperWeld C Solid Size | 6 AWG |
| Conductor - CopperWeld Solid Size Range | 6 AWG |
| Conductor - CopperWeld Str Size | 6 AWG |
| Conductor - CopperWeld Str Size Range | 6 A AWG-6 D AWG |
| Conductor - Material | Copper |
| Certification - CSA Approved | Yes |
| Certification - ETL | No |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Industry Standard(s) | UL 486A-486B |
| Standards - RoHS Compliance Status | CM |
| UL Listed | Yes |
