Buy Burndy YA39L2NTCFX, 510461 Hylug 600 Kcmil Two Hole 1/2 Stud Size, (Pack of 10 pcs)

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Package Quantity: Pack of 10 pcs

600 kcmil G,H,I,K, 1470/24 DLO CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Black Color Code, 24 Die Index

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Color Code	Purple
Connector Type	Terminal
Die Index	23;400
Feature - Barrel Style	Chamfered
Feature - Barrel Type	Standard
Material	Copper
Physical Attribute - Number of Holes	2
Plated	Y
Plating Type	Tin
Trade Name	HYLUG
Type	Standard Barrel, Tin Plated
UPC	781810147290
UPC 12 Digit	7818101472900
Dimension - B Length fraction	1-7/16 in
Dimension - B Length inch	1.42 in
Dimension - Bolt Hole Size inch	0.52 in
Dimension - Bolt Size fraction	1/2
Dimension - Hole Size inch	0.56 in
Dimension - Hole Size mm	14 mm
Dimension - L Length Overall mm	136 mm
Dimension - Length Overall inch	5.36 in
Dimension - N inch	0.63 in
Dimension - Outside Diameter inch	1.30 in
Dimension - Pad Width inch	1.91 in
Dimension - Strip Length inch	1-3/8
Dimension - Z inch	0.65 in
Physical Attribute - Tongue Angle	Straight
Rating - KVA	35 kV
Voltage - Maximum	35000
Conductor - Copper DLO Size Range	1470/24
Conductor - Copper Flex G Size	600 kcmil
Conductor - Copper Flex G Size Range	600 kcmil
Conductor - Copper Flex H Size	600 kcmil
Conductor - Copper Flex H Size Range	600 kcmil
Conductor - Copper Flex I Size	600 kcmil
Conductor - Copper Flex I Size Range	600 kcmil
Conductor - Copper Flex K Size	600 kcmil
Conductor - Copper Flex K Size Range	600 kcmil
Conductor - Copper Flex M Size	600 kcmil
Conductor - Copper Flex M Size Range	600 kcmil
Conductor - Copper Str Size Range	600 kcmil
Conductor - Material	Copper

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Color Code	Purple
Connector Type	Terminal
Die Index	23;400
Feature - Barrel Style	Chamfered
Feature - Barrel Type	Standard
Material	Copper
Physical Attribute - Number of Holes	2
Plated	Y
Plating Type	Tin
Trade Name	HYLUG
Type	Standard Barrel, Tin Plated
UPC	781810147290
UPC 12 Digit	7818101472900
Dimension - B Length fraction	1-7/16 in
Dimension - B Length inch	1.42 in
Dimension - Bolt Hole Size inch	0.52 in
Dimension - Bolt Size fraction	1/2
Dimension - Hole Size inch	0.56 in
Dimension - Hole Size mm	14 mm
Dimension - L Length Overall mm	136 mm
Dimension - Length Overall inch	5.36 in
Dimension - N inch	0.63 in
Dimension - Outside Diameter inch	1.30 in
Dimension - Pad Width inch	1.91 in
Dimension - Strip Length inch	1-3/8
Dimension - Z inch	0.65 in
Physical Attribute - Tongue Angle	Straight
Rating - KVA	35 kV
Voltage - Maximum	35000
Conductor - Copper DLO Size Range	1470/24
Conductor - Copper Flex G Size	600 kcmil
Conductor - Copper Flex G Size Range	600 kcmil
Conductor - Copper Flex H Size	600 kcmil
Conductor - Copper Flex H Size Range	600 kcmil
Conductor - Copper Flex I Size	600 kcmil
Conductor - Copper Flex I Size Range	600 kcmil
Conductor - Copper Flex K Size	600 kcmil
Conductor - Copper Flex K Size Range	600 kcmil
Conductor - Copper Flex M Size	600 kcmil
Conductor - Copper Flex M Size Range	600 kcmil
Conductor - Copper Str Size Range	600 kcmil
Conductor - Material	Copper

Note

Note: Please read description carefully. Do not base your order on the picture presented.
