Buy Burndy CL501TN, Copper Lay-in Lug, 14-4 AWG, #10 Stud, Tin Plated, (Pack of 100 pcs)

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Package Quantity: Pack of 100 pcs

Options and Related Products

Plating Type:: Plating Type: Tin Plated

Features:

The lay-in Qik lug is manufactured from high-strength pure electrolytic copper to ensure maximum strength and conductivity.
The open-faced design allows for fast lay-in of the conductor without the need for cutting or breaking.

See more product information See less

Return and Warranty

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

***

warning WARNING: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Product Details

Application	For Direct Burial Applications in Concrete Or Earth, for Fast Lay-In Of The Conductor Without The Need for Cutting Or Breaking, for Solar Panel Grounding
EU RoHS Indicator	Yes
Material	Copper
Material - Hardware	Stainless Steel
Plated	Y
Plating Type	Tin - Electro Plated
Sub Brand	QIKLUG
Trade Name	QIKLUG
Type	Open-Faced
Dimension - D inch	0.47 in
Dimension - Height inch	0.85 in
Dimension - Hole Size inch	0.22 in
Dimension - Hole Size mm	6 mm
Dimension - L Length Overall mm	29 mm
Dimension - Length Overall inch	1.13 in
Dimension - N inch	0.19 in
Dimension - Stud Size inch	17/64
Dimension - Thread Size	-
Dimension - Width inch	0.38 in
Dimension - Width mm	10 mm
Conductor - Copper Solid Size	14 AWG; 13 AWG; 12 AWG; 11 AWG; 10 AWG; 9 AWG; 8 AWG; 7 AWG; 6 AWG; 5 AWG; 4 AWG
Conductor - Copper Solid Size Range	14 AWG-4 AWG
Conductor - Copper Str Size	14 AWG; 12 AWG; 10 AWG; 9 AWG; 8 AWG; 7 AWG; 6 AWG; 5 AWG; 4 AWG
Conductor - Copper Str Size Range	14 AWG - 4 AWG
Conductor Type	CU C Str-Size
Certification - CSA Approved	Yes
Certification - ETL	No
Certification - UL Listed Direct Burial	Y
Certification - UL Recognized	N
Certification - cULus	N
Industry Standard(s)	UL467
Standards - Industry Standards Met	UL467
Standards - RoHS Compliance Status	CM
UL Listed	Yes
