AVU8002A, Line Powered DVI Over Catx Receiver
Unit allow you to extend DVI-D digital video over a maximum of 164 feet (50 meters) of twisted pair cable with the minimum of infrastructure and fuss. Everything is simply powered via USB from the local end, so that no additional power supply is required at the remote, simultaneously saving time and space as well as making installation very straightforward.
The AVU8001A units can support DVI video up to a maximum 165MHz clock rate (1920 x 1200 or 1600 x 1200 at 60Hz, 24-bit color). High-bandwidth Digital Content Protection (HDCP) is supported if HDMI or DisplayPort converters are used with this product. Powered on, the remote unit attempts to read the EDID information from the connected video display. The information is then transferred to the local unit and made available to the computer’s video adapter when required.
Green LED: Flashes to show the unit is operating.
Yellow LED: Flashes if HDCP encoded content is present in the video feed.
