Mini CAT5 Extender Kit, Component Video

Quick Facts

Uses ordinary CAT5 cable to send 1600 x 1200 video up to 300 feet at 85 Hz or 1280 x 1024 video up to 500 feet at 60 Hz.
Eliminates the need for bulky VGA cables.
Buffers and boosts signals for a clear video image.
This single-channel extender connects a remote VGA screen via a receiver.

Further Details

Differential signaling eliminates ground loops and noise.
For extensions up to 300 feet (91.4 m), a single power supply (included) is all you need.
Supports a maximum resolution of 1920 x 1440 noninterlaced at 60 Hz and HDTV at 60 Hz to 1080p.
Compatible with CAT5e or CAT6 cable.
This Component Video kit includes (1) transmitter, (1) receiver, (1) power supply, and (2) cables with (1) HD15 male to (3) RCA male connectors.
Also available are a VGA kit, splitter/extenders that send one signal to 2, 4, or 8 monitors; a transmitter with a local port; and an extender single-gang wallplate transmitter.

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Distance (Maximum)	500 ft. (152.4 m)
Resolution (Maximum)	1600 x 1200 at 300 ft. (91.4 m) or 1280 x 1024 at 500 ft. (152.4 m)
CE Approval	Yes
Connectors	Video input/output: (1) HD15 F on both transmitter and receiver; Interconnect: (1) shielded RJ-45 on both transmitter and receiver
Power	100-240 VAC, 50-60 Hz, autosensing
Size	0.8"H x 1.7"W x 4.5"D (2 x 4.3 x 11.4 cm)
NOTE: For CAT5 video extensions over 300 feet (91.4 m), you'll need to connect a power supply at both ends.
This product works with	CAT5 100-MHz Solid-Conductor Cable, 4-Pair, Straight-Pinned (EYN556MS, EYN550MS)

Distance (Maximum)	500 ft. (152.4 m)
Resolution (Maximum)	1600 x 1200 at 300 ft. (91.4 m) or 1280 x 1024 at 500 ft. (152.4 m)
CE Approval	Yes
Connectors	Video input/output: (1) HD15 F on both transmitter and receiver; Interconnect: (1) shielded RJ-45 on both transmitter and receiver
Power	100-240 VAC, 50-60 Hz, autosensing
Size	0.8"H x 1.7"W x 4.5"D (2 x 4.3 x 11.4 cm)
NOTE: For CAT5 video extensions over 300 feet (91.4 m), you'll need to connect a power supply at both ends.
This product works with	CAT5 100-MHz Solid-Conductor Cable, 4-Pair, Straight-Pinned (EYN556MS, EYN550MS)

Note: Please read description carefully. Do not base your order on the picture presented.
