| Performance |
| Circulation method | Air velocity control, Forced air circulation(with manual slide type exhaust damper) |
| Operating temperature range | Room temp. +10 to 260deg.C |
| Temp. adjustment accuracy | ±0.5deg.C (at 260deg.C) |
| Temp. distribution accuracy | ±2.5deg.C (max. air velocity, at 260deg.C) |
| Max. temp. reaching time | Approx. 60 min. |
| Components |
| Interior/Exterior material | Stainless steel /Electro-galvanized steel sheet with epoxy and melamine resin baking finish |
| Heat insulating material | Glass wool |
| Heater | Stainless pipe heater,
1.35 kWx2 |
| Fan Type | Scirocco fan |
| Motor | DC24V, Brushless motor (800～1,500rpm) variable type (10 steps), 50W |
| Cable hole/Air in-take hole | 30mm I.D. (the right side) each 1pc. |
| Exhaust port | 50mm I.D.x1 pc. (the back) |
| Controller |
| Temp. controller | PlD control by microprocessor |
| Temp. setting method | Digital setting by UP/DOWN key |
| Temp display method | Digital display by Orange LED (4 digit) |
| Timer/Min.division | 0 min. to 999 Hrs. 59 min. /1 min. |
Operation function
Program mode | Fixed temperature operation, Program operation, Auto start, Auto-stop,
Program operation; Maximum 32 steps, Repeat function |
| Additional functions | Timer (Total operating hours : max. 49,999 Hrs.), Calibration offset function, Time display, Fan stop |
| Heater circuit control | Triac zero-cross control |
| Sensor | K-thermocouple |
| Safe Device |
| Safety countermeasures | Self diagnosis functions (temp. sensor abnormal, Heater disconnection, SSR- short, Main relay abnormal, Automatic overheating prevention), Key lock function, Independent overheat prevention, Electric leakage breaker with over current protection |
| Standard |
Internal dimensions (WxDxHmm)
External dimensions(WxDxHmm)
Internal capacity | 600x500x1,000
730x696x1,675
300 liters |
| Shelf plate with standard load | Approx. 15kg/piece |
| Shelf rest step number | 29 steps |
| Shelf rest pitch | 30 mm |
| Power source 50/60Hz | AC 220V
single phase
13.6A |
| weight | Approx. 113 kg |
| Accessories |
| Shelf plate | Stainless steel, 4 pcs. |
| Shelf bracket | 8 pcs. (Same as left) |
* The performance shown here is the value under the condition of the ambient temperature of 23deg.C±5deg.C, humidity of 65%RH±20%.
* The projection is not included for Internal dimensions and External dimensions. |
