Buy Yamato BO-601-115V, BO Series Constant Temp Laboratory Oil Bath, 115V

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Easy to use, compact design water bath.

Features:

Digital temperature setting by keys
Protected oil tank prevents burns caused by contact
Equipped with a drain

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Operating Temp. Range

Room temp. +5~180°C

Temp. Adjustment Accuracy

±2°C (at 100°C)

Temp. Control System

PlD control by microprocessor

Temp. Setting / Display Method

Digital setting by keys

Operation Function

Fixed temperature, quick auto-stop, auto stop, auto start

Additional Function

Keypad lock, power failure recovery, calibration off-set

Heater

SUS316 pipeheater 1kW

Sensor

K thermocouple

Safety Device

Bath protection cover
Self-diagnostic function (automatic overheat prevention, temperature sensor error, triac short circuit, heater disconnection, main relay failure), circuit protector, thermal fuse

Water Tank Capacity

~7L

Water Tank Dimensions

ø250 x H150mm / 9.84" x 5.90"

External Dimensions

W310 x D360 x H230mm / 12.20" x 14.17" x 9.05"

Weight

~8kg / 17.63 lb.

Power Source
(50/60 Hz)

AC115V 11A
AC220V 7A

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Operating Temp. Range

Room temp. +5~180°C

Temp. Adjustment Accuracy

±2°C (at 100°C)

Temp. Control System

PlD control by microprocessor

Temp. Setting / Display Method

Digital setting by keys

Operation Function

Fixed temperature, quick auto-stop, auto stop, auto start

Additional Function

Keypad lock, power failure recovery, calibration off-set

Heater

SUS316 pipeheater 1kW

Sensor

K thermocouple

Safety Device

Bath protection cover
Self-diagnostic function (automatic overheat prevention, temperature sensor error, triac short circuit, heater disconnection, main relay failure), circuit protector, thermal fuse

Water Tank Capacity

~7L

Water Tank Dimensions

ø250 x H150mm / 9.84" x 5.90"

External Dimensions

W310 x D360 x H230mm / 12.20" x 14.17" x 9.05"

Weight

~8kg / 17.63 lb.

Power Source
(50/60 Hz)

AC115V 11A
AC220V 7A

Note

Note: Please read description carefully. Do not base your order on the picture presented.
