| Thermal Imaging |
| Color Palettes | Iron, rainbow, arctic, white hot and black hot |
| Focus | Fixed |
| Sensitivity | 150 mK |
| Field of View [V x H] | 44 x 57° |
| Thermal Imaging Detector | FLIR Lepton microbolometer |
| IR | - Spectral response: 8 to 14 µm
- Temperature measurement range: 14 to 572°F (-10 to 300°C)
- Temperature resolution: 0.1°F (0.1°C)
- Temperature accuracy: ±5.4°F (3°C) or ±3% of the reading; whichever is greater
|
| Emissivity Adjustment | 0.1 to 1 (default is 0.95); select from three presets or set manually |
| Laser | - Pointer type: Class 1
- Pointer power: ≤0.39 mW
- Wavelength: 640 to 660 nm
|
| Display | 2.4" (609 mm) TFT screen |
| Storage Media | eMMC 8 GB |
| IR Resolution | 160 x 120 (19,200 pixels) |
| Image Modes | Thermal MSX (Multi Spectral Dynamic Imaging), thermal camera only, digital camera only |
| Visual Imaging |
| Resolution | Resolution: 2 MP (1600 x 1200 pixels) |
| Focus | Fixed |
| Field of View | 71° x 56° |
| Measurements and Analysis |
| AC/DC | - Current: Range 600 A/basic accuracy ±2%
- Voltage: Range 1000 V/basic accuracy ±1%
|
| Auto Range | Yes, with manual range option |
| Capacitance | Range 1000 µF/basic accuracy ±1% |
| Continuity Check Threshold | <30 Ω beeper on, >150 Ω beeper off |
| Diode Range | 1.5 V/basic accuracy ±1.5% |
| Flex Input | - AC A: Range 3000 A/basic accuracy ±1%
- Frequency counter: Range 10 kHz/basic accuracy ±0.1%
|
| Inrush AC Current Range | 600 A/basic accuracy ±3% |
| LoZ Mode | - AC voltage: Range 60, 600, 1000 V/basic accuracy ±1%
- DC voltage: Range 60, 600, 1000 V/basic accuracy ±1%
|
| Measuring Rate | 3 samples per second |
| Resistance | Range 60 KΩ/basic accuracy ±1% |
| Temperature | - Accuracy: ±5.4°F (3°C) or ±3% of rdg; whichever is greater
- Range: 14 to 572°F (-10 to 300°C)
|
| True RMS | Yes |
| VFD | - AC current: Range 600 A/basic accuracy ±2%
- AC voltage: Range 1000 V/basic accuracy ±1%
|
| PV | - DC V: Range 1000 V/basic accuracy ±2%, range 1500 V/basic accuracy ±2% with optional accessories test leads (sold separately)
- DC power: Range 900 kVA/basic accuracy ±2%
|
| General Specifications |
| Communication & Data Storage | - Connectivity: Bluetooth
- Data logging and storage: 10 sets of 40 K scalar measurements, 30 K images
|
| Power | - Auto power off
- For device: option to OFF, 2, 5, or 10 minutes
- For worklight only: option to OFF, 5, 15, or 30 minutes
- Battery: Rechargeable 3.7 V, 5400 mAh LiPo
|
| Drop Test | 6.5' (2 m) |
| Product Certifications | cULus, CE, FCC, UKCA |
| ROHS and Reach Directive | Yes |
| IP Rating | IP40 |
| Worklights | 2 x white LED |
| Dimension | - 10.7 x 3.94 x 2" (272 x 100 x 51.5 mm)
- Jaw opening: 1.37" (35 mm)
|
| Weight | 2.8 lbs (560 g) |
