Spartan Scientific Series 3580 Air-Solenoid Operator Valve

The Spartan Scientific Series 3580 is an engineered composite 2-Way, 2-Position solenoid/air operated valve designed for the control of liquid media and inert gas. The valve exhibits a large 1/2" orifice and three port sizes standard, 1/4", 3/8" and 1/2" NPT. The Normally Open version of the 3580 has a unique operator that allows for function without the use of a bypass tube as with the 3510 and has a push non-locking and a turn-lock manual override. The valve's compact design utilizes the latest in material sciences with the use of composite materials in the valve body. The solenoid pilot is power saving low wattage, made of stainless steel working components and is miniaturized to fit in tight places. Standard elastomers available are FKM, NBR, and EPDM. The fully encapsulated coils are available in all standard voltages and with spaded, flying leads or with a connector attached. Typical applications are for installations where there is a need to control inert fluids and gases, condensate drainage, hot water plumbing and sprinkler systems.

For more information, please see Data Sheet
