SAER, 6BP 5/110, 6 BP Series Electric Centrifugal Pump, 2Hp, 230V, Max. Head 78ft, GPM 176
Applications
Electric pumps 6BP series can be used for surface flooding and spray irrigation systems, lifting water from lakes, rivers and tanks, and for various industrial applications.
Pump Construction
Pump body and motor support in cast iron. Wide range of available material for the impellers: cast iron, carbon steel, brass, precision cast stainless steel and marine bronze. Mechanical seal in graphite/ceramic, totally enclosed motor with external ventilation, rotor mounted on maintenance-free ball bearings. The pumps can be supplied with a built-in thermal overload protection on request. The capacitor is permanently in circuit in the single-phase version.
Installation
The series BP electric pumps can be installed with the motor shaft mounted either horizontally or vertically. In the event of vertical installations, the motor must always be positioned above the pump body.
