Buy Morris 22047, 12 Pole 20A Terminal Block - Mega Depot

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Number of Poles:: Number of Poles: 12

12 Pole 20A Terminal Block

Features:

Nylon insulated terminal strips are popular to alternative splicing
High density circuitry can be attained to conserve space
Rated: 20A UL 300VAC CSA 600VAC
.43" Center Spacing
Nylon Insulation Withstands Voltage: AC 2000V/min
Insulation Resistance: 1000M or More at DC500V
Using Temperature Range: -40°F to 248°F (-40°C to 120°C)
Screw Torque Value: 18 Kg-cm
Wire Range Awg: 12-22 Str
Insulator Body: Plastic Nylon 66 (UL 94V-0)
Brass Tin Plated Terminals 0.8t
Terminal Screws: M4 Nickel Plated Brass
cURus/CSA Listed

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Poles	12
Length	5.93"
Width	.87
Min Order Qty	1

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

warning WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov

Product Details

Poles	12
Length	5.93"
Width	.87
Min Order Qty	1

Note: Please read description carefully. Do not base your order on the picture presented.
