Mahr 4484059 Marameter 844 DR Indicating Plug Gage, 190-200 mm Range

Model for through holes and norrow parts

Features:

• Measuring probe made of hardened, stainless guide cylinder and carbide tipped probes
• Carbide driving needle transfers radial measuring movement to the display unit
• Constant measuring force as a result of built-in spring, eliminating user influence
• Measuring head, measuring instrument holder, depth extensions, right angle attachments and depth stops form a comprehensive modular system

Applications:

• With extended guide cylinder for measuring through holes and bores of narrow parts e.g. sheets
• For the rapid testing of diameter, roundness and conicity of bores
• Especially suitable for testing batches with tight tolerance zones 10 µm and more
• Rocking in the bore is not required to determine diameter
• Ideal for use in conjunction with digital display units and for subsequent processing of measured values
