| Max. Resolution | 3840 x 2160 |
| Image Sensor | 1/1.8" progressive scan CMOS |
| Min. Illumination | Color: 0.005 Lux at (F1.5, AGC on); B/W: 0.001 Lux at (F1.5, AGC on); 0 Lux with IR |
| Shutter Speed | 1/1 to 1/30000 sec. |
| Slow Shutter | Yes |
| Day & Night | IR cut filter |
| Zoom | 25x optical, 16x digital |
| Focal Length | 5.9 to 147.5 mm |
| Zoom Speed | Approx. 4.8 sec. |
| Field of View | Horizontal: 50.8° to 2.6° (wide-tele); Vertical: 29.4° to 1.5° (wide-tele); Diagonal: 57.4° to 3° (wide-tele) |
| Aperture | Max. F1.5 |
| Focus | Auto, semi-auto, manual, rapid focus |
| Supplemental Light Range | Up to 655 ft (200 m) |
| Supplemental Light Type | IR |
| Movement Range (Pan) | 360° |
| Movement Range (Tilt) | -15° to 90° (auto flip) |
| Pan Speed | Configurable from 0.1° to 160°/sec.; preset speed: 240°/sec. |
| Tilt Speed | Configurable from 0.1° to 120°/sec.; preset speed: 200°/sec. |
| Proportional Pan | Yes |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans |
| Power-off Memory | Yes |
| Park Action | Preset, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning | Yes |
| PTZ Status Display | Yes |
| Preset Freezing | Yes |
| Scheduled Task | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
| Main Stream | 24 fps (3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 960, 1280 x 720) |
| Sub-Stream | 24 fps (704 x 480, 640 x 480, 352 x 240) |
| Third Stream | 24 fps (1920 x 1080, 1280 x 960, 1280 x 720, 704 x 480, 640 x 480, 352 x 240) |
| Video Compression | Main stream: H.264/H.264+/H.265/H.265+; Sub-stream: MJPEG/H.264/H.265; Third stream: MJPEG/H.264/H.265 |
| Video Bit Rate | 32 Kbps to 16.3 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 8 fixed regions for each stream |
| Audio Compression | G.711 alaw, G.711 ulaw, G.722.1, G.726, MP2L2, AAC, PCM |
| Audio Bit Rate | 64 Kbps (G.711); 16 Kbps (G.722.1); 16 Kbps (G.726); 32 to 192 Kbps (MP2L2); 16 to 64 Kbps (AAC) |
| Audio Sampling Rate | 8/16/32/48 kHz |
| Environment Noise Filtering | Yes |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, Websocket, Websockets |
| API | ONVIF (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| Simultaneous Live View | Up to 20 channels |
| User / Host | Up to 32 users, 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address) |
| Client | NVMS V3, X-VMS, LTS Connect APP |
| Web Browsers | IE 11, Chrome 57+, Firefox 52+, Safari 11+ |
