| Image Sensor (Fixed channel) | 1/3" Progressive Scan CMOS |
| Image Sensor (PTZ channel) | 1/2.8" Progressive Scan CMOS |
| Min. Illumination (Fixed channel) | 0.0005 Lux at (F1.0, AGC on), 0 Lux with light |
| Min. Illumination (PTZ channel) | Color: 0.005 Lux at (F1.6, AGC on); B/W: 0.001 Lux at (F1.6, AGC on); 0 Lux with IR |
| Shutter Speed | 1 to 1/30,000 sec. |
| Slow Shutter | Yes |
| Focus | Semi-auto, manual, auto |
| Zoom (PTZ channel) | 25x optical, 16x digital |
| Day & Night | ICR |
| Day / Night Switch | Day, night, auto, scheduled-switch |
| White Balance | Auto, ATW, sodium lamp, fluorescent lamp, indoor, outdoor, MWB, Locked WB |
| Max. Resolution (Fixed channel) | 2560 x 1440 |
| Max. Resolution (PTZ channel) | 2560 x 1440 |
| Focal Length (Fixed channel) | 2.8 mm |
| Focal Length (PTZ channel) | 4.8 to 120 mm, 25x optical |
| Zoom Speed (PTZ channel) | Approx. 3.6 sec. |
| Field of View (Fixed channel) | Horizontal: 96.1°, Vertical: 52.1°, Diagonal: 113.3° |
| Field of View (PTZ channel) | Horizontal: 55° to 2.4° (wide-tele); Vertical: 33° to 1.4° (wide-tele); Diagonal: 61.5° to 2.8° (wide-tele) |
| Aperture (Fixed channel) | F1.0 |
| Aperture (PTZ channel) | F1.6 |
| Supplemental Light Types (PTZ channel) | IR |
| Supplemental Light Types (Fixed channel) | White Light |
| Smart Supplemental Lighting | Yes |
| Supplemental Light Range (PTZ channel) | Up to 328 ft (100 m) |
| Supplemental Light Range (Fixed channel) | Up to 98 ft (30 m) |
| Movement Range (Pan) | 360° |
| Movement Range (Tilt) | -15° to 90° (auto flip) |
| Pan Speed | Configurable from 0.1° to 80°/sec.; preset speed: 80°/sec. |
| Tilt Speed | Configurable from 0.1° to 80°/sec.; preset speed: 80°/sec. |
| Proportional Zoom | Yes |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans |
| Power-off Memory | Yes |
| Park Action | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning | Yes |
| PTZ Status Display | Yes |
| Preset Freezing | Yes |
| Scheduled Tasks | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
| Anomaly Detections | IP address conflict, HDD full, illegal login, HDD error, network disconnected, abnormal reboot |
