LTS, POE-SW401, 4 PoE Port Switch with 1 Up Link Port 58W - 802.3AF/AT - 10/100Mbps Up to 660 Ft

PoE Transmit Power and Data, distance up to 820ft, 4 PoE Ports + 1 Uplink

Features:

IEEE 802.3at and IEEE802.3af PoE compliant
Distance up to 820ft
Extend mode up to 820ft
4 PoE Ports + 1 Uplink
Provides up to 30 watts per PoE port
Supports PoE power up to 58W for all ports
4kV surge Protection for PoE ports
1Gbps switching fabric
448 Kbits RAM Data Buffer
1K MAC address Entries
Metal Enclosure
Plug and Play Installation

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Network Ports	5
Network Protocol	IEEE80 2.3,8 02.3u,802.3 x, 802.3af, 802.3at
Switching Capacity	1Gbps
Uplink Port	100M Ethernet Port, 1
Max. Forwarding Rate	0.74Mpps
High Priority Ports	Ports 1
Forwarding Mode	Store-and-forward
MAC Address Table	1k
Flow Control	IEEE802.3x full duplex
PoE Port	4
PoE Standard	802.3af, 802.3at
PoE Power Budget	58W
Working Mode	Supports 8 pins powering
Power Supply	51V DC, 1.25A
Power Consumption	≤63W
Working Temperature	32°F ~ 104°F(0- 40)
Working Humidity	10 % ~ 90 %
Surge Protection	4KV
Dimensions	132 x 93.3 x 27.6 mm(5.2" x 3.67"x 1.09")
Weight	≤ 0.3kg(0.66lb)

Product Details

Network Ports	5
Network Protocol	IEEE80 2.3,8 02.3u,802.3 x, 802.3af, 802.3at
Switching Capacity	1Gbps
Uplink Port	100M Ethernet Port, 1
Max. Forwarding Rate	0.74Mpps
High Priority Ports	Ports 1
Forwarding Mode	Store-and-forward
MAC Address Table	1k
Flow Control	IEEE802.3x full duplex
PoE Port	4
PoE Standard	802.3af, 802.3at
PoE Power Budget	58W
Working Mode	Supports 8 pins powering
Power Supply	51V DC, 1.25A
Power Consumption	≤63W
Working Temperature	32°F ~ 104°F(0- 40)
Working Humidity	10 % ~ 90 %
Surge Protection	4KV
Dimensions	132 x 93.3 x 27.6 mm(5.2" x 3.67"x 1.09")
Weight	≤ 0.3kg(0.66lb)

Note: Please read description carefully. Do not base your order on the picture presented.
