Buy LTS LTD8508D-STC, 8-ch 5 MP 1U H.265 Direct Search DVR

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Platinum, DVR, 8MP, 8ch Analog + 8ch IP (up to 8MP), 4K at8fps/3K at12fps, H.265 Pro+, Facial Recognition/Perimeter Protection, 1U, 1 SATA (up to 10TB), HDTVI Two-Way Audio, Smart Playback, 5-in-1 Signals

Features

8 channels and 1 HDD 1U Direct Search DVR
Support 4-ch Facial Recognition or 8-ch advanced model Perimeter Protection based on Deep Learning algorithm
Support 8-ch Direct Search Technology
Encoding ability up to 4K/8MP at 8fps; 3K/5MP at12fps
Up to 16 channels IP camera inputs, each channel up to 8MP
Up to 24*1080P at30fps decoding ability
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Support All channels Motion Detection Technology
Support All channels HDTVI Two-Way Audio Technology
Up to 8 channels (analog channel) Motion Detection 2.0
Up to 8 channels (advanced model, analog channel) Perimeter Protection
Up to 4 channels (advanced model, analog channel) human face recognition
Support smart playback to enhance playback efficiency

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Parameter	LTD8508D-STC, 8-ch 5 MP 1U H.265 Direct Search DVR
Facial Recognition
Face Picture Library	Up to 16 face picture libraries; Library backed up by HDD and flash to prevent data loss in case of HDD damage
Face Picture Comparison	4-ch face picture comparison alarm (HD analog camera)
Perimeter Protection
Human/Vehicle Analysis	Up to 8-ch (advanced model)
Facial Detection
Face Detection & Capture	Face picture detection and search; 4-ch face picture capture
Video and Audio
IP Video Input	8-ch (expandable up to 16-ch), each up to 8 MP
Analog Video Input	8-ch, BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDMI Output	1-ch; 4K (3840 × 2160) at 30 Hz; 2K (2560 × 1440) at 60 Hz; 1920 × 1080 / 1280 × 1024 / 1280 × 720 at 60 Hz; HDMI/VGA simultaneous output
VGA Output	1-ch; 1920 × 1080 / 1280 × 1024 / 1280 × 720 at 60 Hz; HDMI/VGA simultaneous output
CVBS Input	PAL / NTSC
CVBS Output	1-ch, BNC (1.0 Vp-p, 75 Ω); PAL: 704 × 576; NTSC: 704 × 480
Synchronous Playback	8-ch
HDTVI Input	8 MP (3840 × 2160) at 12/15 fps; 3K at 20/25 fps; 5 MP at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps
AHD Input	5 MP at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps
HDCVI Input	8 MP at 12/15 fps; 3K at 20/25 fps; 5 MP at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps
Audio Input	1-ch, RCA (2.0 Vp-p, 1 KΩ); 8-ch via coaxial cable
Audio Output	1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio	1-ch, RCA (2.0 Vp-p, 1 KΩ), using first audio input
Recording
Video Compression	H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Encoding Resolution	8 MP / 5 MP / 3K / 4 MP / 3 MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF
Frame Rate (Main Stream)	8 MP at 8 fps; 3K at 12 fps; 5 MP at 12 fps; 4 MP at 15 fps; 8 MP Lite at 15 fps; 3 MP at 18 fps; 1080p / 720p / WD1 / 4CIF / VGA / CIF at 25 fps (P) / 30 fps (N)
Frame Rate (Sub-Stream)	WD1 / 4CIF / CIF at 25 fps (P) / 30 fps (N)
Video Bitrate	32 Kbps to 10 Mbps
Dual-Stream	Supports main stream or sub-stream
Stream Type	Video / Video & Audio
Audio Compression	G.711u
Audio Bitrate	64 Kbps

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Parameter	LTD8508D-STC, 8-ch 5 MP 1U H.265 Direct Search DVR
Facial Recognition
Face Picture Library	Up to 16 face picture libraries; Library backed up by HDD and flash to prevent data loss in case of HDD damage
Face Picture Comparison	4-ch face picture comparison alarm (HD analog camera)
Perimeter Protection
Human/Vehicle Analysis	Up to 8-ch (advanced model)
Facial Detection
Face Detection & Capture	Face picture detection and search; 4-ch face picture capture
Video and Audio
IP Video Input	8-ch (expandable up to 16-ch), each up to 8 MP
Analog Video Input	8-ch, BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDMI Output	1-ch; 4K (3840 × 2160) at 30 Hz; 2K (2560 × 1440) at 60 Hz; 1920 × 1080 / 1280 × 1024 / 1280 × 720 at 60 Hz; HDMI/VGA simultaneous output
VGA Output	1-ch; 1920 × 1080 / 1280 × 1024 / 1280 × 720 at 60 Hz; HDMI/VGA simultaneous output
CVBS Input	PAL / NTSC
CVBS Output	1-ch, BNC (1.0 Vp-p, 75 Ω); PAL: 704 × 576; NTSC: 704 × 480
Synchronous Playback	8-ch
HDTVI Input	8 MP (3840 × 2160) at 12/15 fps; 3K at 20/25 fps; 5 MP at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps
AHD Input	5 MP at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps
HDCVI Input	8 MP at 12/15 fps; 3K at 20/25 fps; 5 MP at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps
Audio Input	1-ch, RCA (2.0 Vp-p, 1 KΩ); 8-ch via coaxial cable
Audio Output	1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio	1-ch, RCA (2.0 Vp-p, 1 KΩ), using first audio input
Recording
Video Compression	H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Encoding Resolution	8 MP / 5 MP / 3K / 4 MP / 3 MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF
Frame Rate (Main Stream)	8 MP at 8 fps; 3K at 12 fps; 5 MP at 12 fps; 4 MP at 15 fps; 8 MP Lite at 15 fps; 3 MP at 18 fps; 1080p / 720p / WD1 / 4CIF / VGA / CIF at 25 fps (P) / 30 fps (N)
Frame Rate (Sub-Stream)	WD1 / 4CIF / CIF at 25 fps (P) / 30 fps (N)
Video Bitrate	32 Kbps to 10 Mbps
Dual-Stream	Supports main stream or sub-stream
Stream Type	Video / Video & Audio
Audio Compression	G.711u
Audio Bitrate	64 Kbps

Note

Note: Please read description carefully. Do not base your order on the picture presented.
