LTAH5100T, HD-TVI Converter

Features:

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Physical Interface	BNC, HDMI
Input Level	>500 mVp-p
Output Format	HDMI 1.4b, A standard interface
Input Auto Cable Equalization	1080 p, 720 p, supporting 100M75-5 cable input with distance of 100M
Input Format	1080 p 25/30, 720 p 25/30/50/60, compatible with V2.0 HDTVI
Input Impedance	75 Ω
Output Resolution	720 p 50/60, 1080 p 50/60
Output Format Distance	HDMI 1.4b, D-type base, 10 M distance
LED	Power LED, video source LED
Power Supply	12 VDC, 1A
Power Consumption	≤ 8 W
Working Humidity	10 % to 90 %
Working Temperature	-86º F to + 167º F
Dimensions (WxDxH)	2.0 x 1.2 x 1.0"
Mounting Type	Independent

Physical Interface	BNC, HDMI
Input Level	>500 mVp-p
Output Format	HDMI 1.4b, A standard interface
Input Auto Cable Equalization	1080 p, 720 p, supporting 100M75-5 cable input with distance of 100M
Input Format	1080 p 25/30, 720 p 25/30/50/60, compatible with V2.0 HDTVI
Input Impedance	75 Ω
Output Resolution	720 p 50/60, 1080 p 50/60
Output Format Distance	HDMI 1.4b, D-type base, 10 M distance
LED	Power LED, video source LED
Power Supply	12 VDC, 1A
Power Consumption	≤ 8 W
Working Humidity	10 % to 90 %
Working Temperature	-86º F to + 167º F
Dimensions (WxDxH)	2.0 x 1.2 x 1.0"
Mounting Type	Independent
