| Camera | - Image Sensor: 1/1.8" Progressive Scan CMOS
- Max. Resolution: 3840 × 2160
- Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
- Shutter Time: 1 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Lens Type: 2.8 mm Fixed focal lens
- FOV: Horizontal 108.8°, Vertical 56.4°, Diagonal 134.3°
- Lens Mount: M16
- Iris Type: Fixed
- Aperture: F1.0
- Depth of Field: 3.3 m to ∞
|
| DORI | - 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m
|
| Illuminator | - Supplement Light Type: White Light, IR
- Supplement Light Range: Up to 60 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
|
| Video | - Main Stream:
- 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Supported under certain settings
- Video Compression:
- Main: H.265 / H.264 / H.264+ / H.265+
- Sub: H.265 / H.264 / MJPEG
- Third: H.265 / H.264
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- SVC: H.264 and H.265 encoding
- ROI: 1 fixed region for main stream
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
- Simultaneous Live View: Up to 6 connections
- API: ONVIF (Profile S, T, G), ISAPI, SDK, ISUP
- Users: Up to 32 (administrator, operator, user)
- Security: Password protection, HTTPS encryption, 802.1X (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP filter, TLS 1.1/1.2/1.3, MAC authentication
- Network Storage: NAS (NFS, SMB/CIFS), ANR
- Client: NVMSV3, LTS CONNECT, X-VMS
- Web Browser: Chrome 80+, Firefox 80+, Edge 89+
|
| Image | - Image Parameters Switch: Yes
- Image Settings: Rotate, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR, Distortion Correction, Defog
- SNR: ≥ 52 dB
- WDR: 130 dB
- Image Stabilization: EIS
- Privacy Mask: 4 programmable polygon masks
|
| Interface | - Ethernet: 1 × RJ45 10/100M self-adaptive
- On-Board Storage: microSD/microSDHC/microSDXC up to 512 GB
- Reset Key: Yes
|
| Events & Smart | - Motion Detection (human/vehicle classification)
- Video Tampering Alarm
- Scene Change Detection
- Face Capture
- Perimeter Protection: Line crossing, intrusion, region entrance, region exiting
- Linkage: FTP/NAS upload, email notification, recording, capture
|
| General | - Power: 12 VDC ±25%, 0.83 A, max. 10 W; PoE IEEE 802.3af, Class 3, max. 12.5 W
- Material: Front cover / body / bracket - Metal
- Dimensions: 286.7 × 93.3 × 91.2 mm
- Weight: 1200 g; With package: 1745 g
- Operating Conditions: -30 °C to 60 °C, ≤95% humidity
- Functions: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
- Languages: 33 languages supported
- Protection: IP67, NEMA 4X
|
| Approval | - EMC: CE-EMC, RCM, IC, KC
- Safety: IEC 62368-1, EN 62368-1
- Environment: CE-RoHS (2011/65/EU)
|
