| Camera | - Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2688 × 1520
- Min. Illumination: Color 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light
- Shutter Time: 1/3 sec. to 1/100,000 sec.
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Type: Fixed focal lens, 2.8 mm
- Field of View: Horizontal 100.2°, Vertical 54.7°, Diagonal 119.7°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.0
- Depth of Field: 1.9 m to ∞
|
| DORI | - Detection: 63 m
- Observation: 25 m
- Recognition: 12 m
- Identification: 6 m
|
| Illuminator | - Supplemental Light: IR, White Light
- Supplemental Light Range: Up to 60 m
- Smart Supplemental Lighting: Yes
- IR Wavelength: 850 nm
|
| Video | - Main Stream: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream: 10 fps (up to 1920 × 1080)
- Compression: H.265 / H.264 / H.264+ / H.265+
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Profile: Baseline / Main / High
- H.265 Profile: Main
- Bit Rate Control: CBR / VBR
- SVC: H.264 and H.265 encoding
- ROI: 1 fixed region (main & sub-stream)
|
| Network | - Protocols: TCP/IP, HTTP/HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, SSL/TLS, PPPoE, SNMP, WebSocket, SRTP, SFTP
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP
- User/Host: Up to 32 users (Administrator, Operator, User)
- Security: HTTPS, 802.1X (EAP-TLS/LEAP/MD5), IP filter, WSSE, TLS 1.1/1.2/1.3, MAC authentication, audit log
- Network Storage: NAS (NFS, SMB/CIFS), ANR
- Client: NVMS, LTS Connect, X-VMS
- Web Browser: IE 10/11, Chrome 57+, Firefox 52+, Edge 89+
|
| Image | - Image Parameters Switch: Yes
- Adjustments: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- SNR: ≥ 52 dB
- WDR: 120 dB
- Privacy Mask: 4 programmable polygon masks
|
| Interface | - Ethernet: 1 RJ45 10M/100M port
- On-Board Storage: MicroSD/SDHC/SDXC up to 512 GB
- Reset Key: Yes
|
| Events & Smart Functions | - Motion Detection (human & vehicle classification)
- Video Tampering Alarm
- Smart Events: Line crossing, intrusion, region entrance/exit, scene change
- Face Capture: Yes
- Linkage: FTP/NAS/memory card upload, recording, capture, email notification
|
| General | - Power: 12 VDC ±25%, 0.6 A, max. 7.2 W
- PoE: IEEE 802.3af, Class 3, max. 9 W
- Material: Metal
- Dimensions: 11.3 × 3.7 × 3.6 in. (286.7 × 93.3 × 91.2 mm)
- Weight: Approx. 2.4 lbs (1,085 g)
- Operating Conditions: -30°C to 60°C; ≤95% humidity
- General Functions: Heartbeat, mirror, password reset via email, pixel counter, anti-banding
- Protection: IP67
|
| Certifications | - EMC: CE-EMC, FCC Part 15 Subpart B
- Safety: UL 62368-1, CB IEC 62368-1, CE-LVD EN 62368-1
- Environmental: CE-RoHS (2011/65/EU)
|
