| Camera | - Image Sensor: 1/2.8" Progressive Scan CMOS
- Min. Illumination: Color 0.005 Lux @ (F1.6, AGC on), B/W 0 Lux with IR
- Shutter Speed: 1/3 to 1/100,000 sec
- Slow Shutter: Yes
- Wide Dynamic Range: 120 dB
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-355°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Type: Varifocal, motorized, 2.8-12 mm
- Field of View: Horizontal 108°-30°, Vertical 56°-17°, Diagonal 131°-35°
- Lens Mount: Ø14
- Iris Type: Fixed
- Aperture: F1.6
|
| DORI | - Detection: 97-290 m
- Observation: 38-115 m
- Recognition: 19-58 m
- Identification: 9-29 m
|
| Illuminator | - Supplemental Light: IR
- Smart Supplemental Lighting: Yes
- IR Wavelength: 850 nm
- IR Range: Up to 197 ft (60 m)
|
| Video | - Max. Resolution: 3840 × 2160
- Main Stream (50 Hz): 20 fps (3840 × 2160), 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Main Stream (60 Hz): 20 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream: 25/30 fps (640 × 480, 640 × 360)
- Third Stream: 10 fps (up to 1920 × 1080)
- Compression: H.264 / H.264+ / H.265 / H.265+
- Bit Rate: 32 Kbps - 16 Mbps
- Bit Rate Control: CBR / VBR
- SVC: H.264 / H.265
- ROI: 1 fixed region (main & sub-stream)
|
| Audio | - Compression: G.711 (ulaw/alaw), G.722.1, G.726, MP2L2, PCM, MP3, AAC
- Bit Rate: 8-320 Kbps (codec dependent)
- Sampling Rate: 8 / 16 / 32 / 44.1 / 48 kHz
- Environmental Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, HTTP/HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, SMTP, SNMP, 802.1X, QoS, IPv4/IPv6, SSL/TLS, PPPoE
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, G), ISAPI, SDK
- User / Host: Up to 32 users (administrator, operator, user)
- Security: HTTPS, IP filter, TLS 1.1/1.2, audit log, WSSE
- Network Storage: NAS (NFS, SMB/CIFS), ANR
- Web Browser: IE 10/11, Chrome 57+, Firefox 52+
|
| Image | - Image Parameters Switch: Yes
- Adjustments: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switching: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- SNR: ≥ 52 dB
|
| Interface | - Ethernet: 1 RJ45 10M/100M port
- Storage: MicroSD up to 256 GB
- Audio: 1 input / 1 output (terminal block)
- Alarm: 1 input, 1 output (max. 24 VDC / 24 VAC, 1 A)
- Hardware Reset: Yes
|
| Events & AI | - Motion Detection (human and vehicle classification)
- Video Tampering Alarm
- Face Detection: Yes
- Perimeter Protection: Line crossing, intrusion detection
|
| General | - Material: Aluminum alloy body
- Dimensions: 12.2 × 3.9 × 3.7 in. (308.5 × 97.9 × 93 mm)
- Weight: Approx. 3.1 lbs (1,385 g)
- Operating Conditions: -30°C to 60°C; ≤95% humidity
- Firmware: V5.5.113
- Power: 12 VDC ±25%, PoE 802.3at Class 4
- Consumption: Max 13 W (12 VDC), 15 W (PoE)
- Protection: IP67, IK10
|
| Certifications | - EMC: FCC, CE-EMC, RCM, IC, KC
- Safety: UL 60950-1, CB, CE-LVD
- Environmental: CE-RoHS, WEEE, Reach
|
