| Camera | - Image Sensor: 1/3' Progressive Scan CMOS
- Min. Illumination: Color 0.005 Lux @ (F1.6, AGC on), 0 Lux with IR on
- Shutter Speed: 1/3 to 1/100,000 sec
- Slow Shutter: Yes
- Wide Dynamic Range: 120 dB
- Day & Night: ICR Cut
- Angle Adjustment: Pan 0°-360°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Focal Length: 2.8-12 mm
- Field of View: Horizontal 95.8°-29.2°, Vertical 50.6°-16.4°, Diagonal 114.6°-33.4°
- Aperture: F1.6
- Lens Mount: Ø14
|
| DORI | - Detection: 64 m - 200 m
- Observation: 25.4 m - 79.4 m
- Recognition: 12.8 m - 40 m
- Identification: 6.4 m - 20 m
|
| Illuminator | - IR Range: Up to 197 ft (60 m)
- IR Wavelength: 850 nm
|
| Video | - Max. Resolution: 2688 × 1520
- Main Stream: 25 fps (50 Hz) / 30 fps (60 Hz) at 2688 × 1520, 1920 × 1080, 1280 × 720
- Sub-Stream: 25 fps / 30 fps at 640 × 480, 640 × 360
- Third Stream: 10 fps at 1920 × 1080, 1280 × 720, 640 × 480, 640 × 360
- Compression: H.264 / H.264+ / H.265 / H.265+
- Bit Rate: 32 Kbps - 8 Mbps
- Bit Rate Control: CBR / VBR
- SVC: Yes
- ROI: 1 fixed region (main & sub-stream)
|
| Audio | - Noise Filtering: Yes
- Sampling Rate: 8 / 16 / 32 / 44.1 / 48 kHz
- Compression: G.711 ulaw / alaw, G.722.1, G.726, MP2L2, PCM, MP3, AAC
- Bit Rate: 8 - 320 Kbps (depending on codec)
|
| Network | - Live View: Up to 6 channels
- API: ONVIF (Profile S, G), ISAPI, SDK
- Protocols: TCP/IP, HTTP/HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, SMTP, 802.1X, IPv6, SSL/TLS, PPPoE and more
- Users: Up to 32 (administrator, operator, user)
- Security: HTTPS, IP filter, TLS 1.1/1.2, audit log, WSSE
- Storage: MicroSD up to 256 GB, NAS (NFS, SMB/CIFS), ANR
- Browser Support: IE 10/11, Chrome 57+, Firefox 52+
|
| Interface | - Audio: 1 input (line in), 1 output (line out)
- Alarm: 1 input, 1 output (max. 12 VDC, 30 mA)
- Ethernet: 1 RJ45 10M/100M port
- On-Board Storage: MicroSD up to 256 GB
- Reset Key: Yes
|
| Events & AI | - Motion Detection: Human and vehicle classification
- Video Tampering Alarm
- Face Detection: Yes
- Perimeter Protection: Line crossing, intrusion detection
|
| General | - Operating Conditions: -30°C to 60°C; ≤95% humidity
- Power Supply: 12 VDC ±25%, PoE 802.3at Class 4
- Power Consumption: Max 13 W (12 VDC), 15 W (PoE)
- Material: Aluminum alloy body
- Dimensions: 12.2 × 3.9 × 3.7 in. (308.5 × 97.9 × 93 mm)
- Weight: Approx. 3.1 lbs (1,390 g)
- Protection: IP67, IK10
|
| Certifications | - EMC: FCC, CE-EMC, RCM, IC, KC
- Safety: UL 60950-1, CB, CE-LVD, BIS
- Environmental: CE-RoHS, WEEE, Reach
|
