| Camera | - Image Sensor: 1/2.5" Progressive Scan CMOS
- Max. Resolution: 2688 × 1520
- Min. Illumination: Color 0.009 Lux @ (F1.6, AGC on), B&W 0.0018 Lux @ (F1.6, AGC on), 0 Lux with IR
- Shutter Time: 1 to 1/30,000 sec
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-355°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Focal Length & FOV: 4.7 to 118 mm; Horizontal 55.8°-2.8°, Vertical 32.3°-1.6°, Diagonal 63°-3°
- Focus: Auto, semi-auto, manual
- Iris Type: P-iris
- Aperture: F1.6 to F3.8
|
| Illuminator | - Supplemental Light: IR
- Range: Up to 656 ft (200 m)
- Smart Supplemental Lighting: Yes
- IR Wavelength: 850 nm
|
| Video | - Main Stream: 50 Hz: 25 fps (multiple resolutions); 50 fps and 60 Hz: 30 fps (multiple resolutions)
- Sub / Third / Fourth / Fifth Streams: Various resolutions, up to 30 fps
- Compression: H.264 / H.264+ / H.265 / H.265+ (Main); MJPEG/H.264/H.265 (Sub/Fourth/Fifth); H.264/H.265 (Third)
- Bit Rate: 32 Kbps - 8 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR / VBR, SVC support
- ROI: 4 fixed regions per stream
- Target Cropping: Yes
- e-PTZ: Patrol & Auto-tracking
|
| Audio | - Type: Mono
- Compression: G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC / MP3
- Sampling Rate: 8/16/32/44.1/48 kHz
- Noise Filtering: Yes
- Bit Rate: 64 Kbps (G.711), 16 Kbps (G.722.1/G.726), 16-64 Kbps (AAC), 32-192 Kbps (MP2L2), 8-320 Kbps (MP3)
|
| Network | - Simultaneous Live View: Up to 20 channels
- API: ONVIF PROFILE S/G/T, ISAPI, SDK, ISUP
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
- User/Host: Up to 32 users, 3 levels (Admin/Operator/User)
- Security: Password protection, HTTPS, 802.1X (EAP-TLS/LEAP/MD5), watermark, IP filter, WSSE/digest authentication, RTP/RTSP over HTTPS, TLS 1.2
- Network Storage: NAS (NFS/SMB/CIFS), ANR
- Web Browsers: IE 10+, Chrome 57+, Firefox 52+, Safari 12+
|
| Image | - Parameter Switching: Yes
- Settings: Saturation, brightness, contrast, sharpness, white balance, AGC
- Day/Night Switch: Day, Night, Auto, Schedule
- WDR: 140 dB
- Enhancement: BLC, HLC, Defog, 3D DNR
- SNR: ≥ 52 dB
- Privacy Mask: 8 programmable polygon masks
- Picture Overlay: 128×128 24-bit BMP
- Image Stabilization: EIS (gyroscope)
|
| Interface | - Video Output: 1 Vp-p Composite (CVBS) - debugging only
- Ethernet: 1 RJ45 10/100/1000 Mbps
- On-Board Storage: microSD/SDHC/SDXC up to 1 TB
- Audio: 1 input, 1 output (3.5 mm, non-equilibrium)
- Alarm: 2 inputs, 2 outputs (max 24 VDC, 1 A)
- Reset Key: Yes
|
| Event & AI | - Basic Events: Motion detection (human/vehicle), tampering, exceptions, video quality diagnosis, vibration detection
- Smart Events: Line crossing, intrusion, region entrance/exit, scene change, audio anomaly, defocus detection
- Linkage: Upload to FTP/NAS/memory card, notify center, send email, trigger alarm/recording/capture
- Deep Learning: Multi-target detection (60 targets), human/face/vehicle features, face capture (60 simultaneously), face comparison (up to 150k per library, 10 libraries)
|
| General | - Power: 12 VDC ±20%, 1.02 A max 12.22 W; 24 VAC ±20%, 0.8 A max 11.49 W; PoE 802.3at Type 2 Class 4 max 10.50 W
- Material: Aluminum alloy body
- Dimensions: Ø5.7 × 14.8 in. (Ø144.1 × 375.2 mm)
- Package: 16.7 × 7.5 × 7.1 in. (425 × 190 × 180 mm)
- Weight: 4.7 lbs (2,130 g); Package Weight: 7.1 lbs (3,200 g)
- Storage/Operating: -30-60 °C (-22-140 °F), humidity ≤95%
- Languages: 33
- Functions: 5 streams, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
|
| Certifications | - EMC: FCC, CE-EMC EN 55032/EN 61000 series, RCM, ICES-003, KC
- Safety: UL 62368-1, CB IEC 62368-1, CE-LVD EN 62368-1, BIS, LOA
- Environmental: CE-RoHS, WEEE, Reach
- Protection: IK10 (IEC 62262), IP67 (IEC 60529)
- Other: PVC FREE
|
