| Camera | - Image Sensor: 1/1.8" Progressive Scan CMOS
- Max. Resolution: 2688 × 1520
- Min. Illumination: Color 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light
- Shutter Time: 1 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Lens Type: Fixed focal, 2.8 mm
- FOV: Horizontal 111.1°, Vertical 57.6°, Diagonal 138.5°
- Lens Mount: M16
- Iris: Fixed, Aperture F1.0
- Depth of Field: 2.5 m to ∞
|
| DORI | 2.8 mm: D 61 m, O 24 m, R 12 m, I 6 m |
| Illuminator | - Supplement Light: White Light + IR
- Range: Up to 40 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
|
| Video | - Main Stream: 50 Hz: 25 fps (2688×1520, 1920×1080, 1280×720); 60 Hz: 30 fps
- Sub Stream: 50 Hz: 25 fps (1280×720, 640×480, 640×360); 60 Hz: 30 fps
- Third Stream: 50/60 Hz: 10 fps (1920×1080, 1280×720, 640×480, 640×360)
- Compression: H.265/H.264/H.264+/H.265+ (Main), H.265/H.264/MJPEG (Sub), H.265/H.264 (Third)
- Bit Rate: 32 Kbps - 8 Mbps
- H.264 Type: Baseline/Main/High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR/VBR, SVC: H.264 & H.265
- ROI: 1 fixed region
|
| Audio | - Type: Mono
- Arrayed dual-microphone
- Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1/G.726)/16-64 Kbps (AAC-LC)/32-192 Kbps (MP2L2)/8-320 Kbps (MP3)
- Sampling Rate: 8/16/32/48 kHz
- Environment Noise Filtering: Yes
|
| Network | - Simultaneous Live View: Up to 6 channels
- API: ONVIF Profile S/G/T, ISAPI, SDK, ISUP
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, SRTP, SFTP
- User/Host: Up to 32 users, 3 levels (Admin/Operator/User)
- Security: Password protection, HTTPS, 802.1X (EAP-TLS/LEAP/MD5), IP filter, WSSE, digest authentication, TLS 1.1/1.2/1.3, MAC authentication
- Network Storage: NAS (NFS/SMB/CIFS), ANR
- Web Browser: Chrome 80+, Firefox 80+, Edge 89+
|
| Image | - Parameters Switch: Yes
- Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switch: Day, Night, Auto, Schedule
- Enhancement: BLC, HLC, 3D DNR, Distortion Correction, Defog
- SNR: ≥ 52 dB
- WDR: 130 dB
- Image Stabilization: EIS
- Privacy Mask: 4 programmable polygon masks
|
| Event & AI | - Basic Events: Motion detection (human/vehicle), video tampering, exceptions
- Smart Event: Scene change detection
- Face Capture: Yes
- Perimeter Protection: Line crossing, intrusion, region entrance/exit, human/vehicle classification
- Linkage: Upload to FTP/NAS/memory card, notify center, trigger recording/capture, send email
|
| General | - Power: 12 VDC ±25%, 0.4 A, max 4.8 W; PoE 802.3af, Class 3, max 6.5 W
- Material: Front cover/body/bracket: metal
- Dimensions: Ø74.4 × 176.3 mm (Ø2.93" × 6.94")
- Package Dimensions: 234 × 120 × 117 mm (9.2" × 4.7" × 4.6")
- Weight: 530 g (1.2 lb), Package Weight: 810 g (1.8 lb)
- Storage/Operating: -30 °C to 60 °C (-22-140 °F), humidity ≤95%
- General Function: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
- Language Support: 33 languages (English, Russian, German, Italian, etc.)
|
| Approval | - EMC: CE-EMC EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM AS/NZS CISPR 32:2015, ICES-003 Issue 7, KC KN32/KN35
- Safety: CB IEC 62368-1:2014+A11, CE-LVD EN 62368-1:2014/A11:2017
- Environment: CE-RoHS, IP67, NEMA 4X (Moderate anti-corrosion protection)
|
