| Camera | - Image Sensor: 1/3" Progressive Scan CMOS
- Min. Illumination: 2.8 mm & 4 mm: Color 0.005 Lux @ (F1.6, AGC ON), B/W 0 Lux with IR
- Max. Resolution: 2688 × 1520
- Shutter Speed: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Focal Length & FOV:
- 2.8 mm: Horizontal 104.3°, Vertical 55.9°, Diagonal 123.8°
- 4 mm: Horizontal 83.7°, Vertical 43°, Diagonal 100.3°
- Aperture: 2.8 mm F1.6, 4 mm F1.6
- Lens Mount: M12
|
| DORI | - 2.8 mm: D 56 m, O 22.2 m, R 11.2 m, I 5.6 m
- 4 mm: D 79.4 m, O 31.5 m, R 15.9 m, I 7.9 m
|
| Illuminator | - IR Range: Up to 33 ft (10 m)
- Wavelength: 850 nm
- Smart Supplement Light: Yes
|
| Video | - Main Stream: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720); 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream: 50 Hz: 25 fps (640 × 480, 640 × 360); 60 Hz: 30 fps (640 × 480, 640 × 360)
- Third Stream: 50/60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Video Compression: H.265/H.264/H.264+/H.265+ (Main), H.265/H.264/MJPEG (Sub), H.265/H.264 (Third)
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR / VBR
- Scalable Video Coding (SVC): Yes
- ROI: 1 fixed region for main & sub-stream
|
| Audio | - Environment Noise Filtering: Yes
- Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Compression: G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
- Bit Rate: 64 Kbps (G.711) / 16 Kbps (G.722.1/G.726) / 16-64 Kbps (AAC) / 32-192 Kbps (MP2L2) / 8-320 Kbps (MP3)
|
| Network & Wi-Fi | - Simultaneous Live View: Up to 6 channels
- API: ONVIF Profile S/G/T, ISAPI, SDK
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
- User/Host: Up to 32 users (admin/operator/user)
- Security: Password protection, HTTPS, IP filter, Audit log, basic/digest HTTP auth, TLS 1.1/1.2, WSSE
- Network Storage: NAS (NFS, SMB/CIFS), ANR
- Web Browser: IE 10/11 (plugin), Chrome 57+, Firefox 52+ (plugin-free)
- Wi-Fi Encryption: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK
- Wi-Fi Protocol: IEEE802.11b/g/n, 2.412-2.472 GHz, 20/40 MHz, Up to 164 ft (50 m)
- Transfer Rate: 11 b/g: 54 Mbps, 11 n: up to 150 Mbps
|
| Image | - WDR: 120 dB
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- Image Parameters Switch: Yes
- Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance
|
| PIR | - Angle: Horizontal 90°, Vertical 80°
- Range: Up to 26 ft (8 m)
|
| Interface | - Built-in Microphone: Yes
- Built-in Speaker: 1 W, Max SPL 91 dB @ 10 cm
- On-board Storage: MicroSD/SDHC/SDXC up to 256 GB
- Hardware Reset: Yes
- Ethernet: 1 RJ45 10/100 M self-adaptive
|
| Event & AI | - Basic Events: Motion detection, video tampering, exceptions
- Face Detection: Yes
- Perimeter Protection: Line crossing, intrusion; supports human & vehicle classification
- Linkage: Upload to FTP/memory card/NAS, notify center, trigger recording/capture, send email, audible warning
|
| General | - Power: 12 VDC ±25%, 0.61 A, max 7.3 W; PoE 802.3af, Class 3, max 8.3 W
- Web Client Languages: 33 languages (English, Russian, German, Italian, etc.)
- General Function: Anti-flicker, heartbeat, password reset via email, pixel counter
- Storage & Operating: -10°C to 40°C (14-104°F), humidity ≤95%
- Camera Material: Plastic
- Dimensions: 102.9 × 65.2 × 32.6 mm (4.1 × 2.6 × 1.3 in)
- Package Dimensions: 150 × 125 × 99 mm (5.9 × 4.9 × 3.9 in)
- Camera Weight: 120 g (0.3 lb), Package Weight: 430 g (0.9 lb)
|
| Approval | - EMC: FCC SDoC, CE-EMC EN 55032:2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014; KC KN32/KN35
- Safety: UL 62368-1; CB IEC 62368-1:2014+A11; CE-LVD EN 62368-1:2014/A11:2017
- Environment: CE-RoHS, WEEE, Reach
|
