| Camera |
| Camera Series | Others |
| Camera Resolution | 3.2MP |
| Camera Technology | IP / Network |
| Camera Housing | Indoor |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.01 lux atF1.2, AGC on
0 lux with IR |
| Shutter Speed | 1/25s ~ 1/100,000s |
| Lens | - 4.0 mm atF2.0
- 2048 x 1536: Angle of view: 70°
- 1920 x 1080:Angle of view: 79°
|
| Lens Mount | M12 |
| Day & Night | IR cut filter with auto switch |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Backlight compensation | Yes,zone configurable |
| Compression Standard |
| Video Compression | H.264 / MJPEG |
| H.264 codec profile | Main profile |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Audio compression | G.711/G.726/MP2L2 |
| Audio bit rate | 64Kbps(G.711) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image |
| Max. Resolution | 2048 x 1536 |
| Frame Rate | - 60Hz: 20fps (2048 x 1536),30fps (1920 x 1080),30fps(1280 x 720)
- 50Hz: 20fps (2048 x 1536),25fps (1920 x 1080),25fps(1280 x 720)
|
| Image Settings | Rotate mode, Saturation, brightness, contrast, sharpeness adjustable through client software or web browser |
| ROI | Yes, up to 3 configurable areas |
| Network |
| Network Storage | Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 6 4GB. NAS |
| Alarm Trigger | Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect,IP address conflict,
Storage exception |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| System compatibility | ONVIF, PSIA, CGI, ISAPI |
| General functionalities | Flickerless, dual stream, heartbeat, mirror, user authentication, video mask, watermark |
| Interface |
| Communication Interface | 1 RJ45 10 M / 100 M Ethernet interface |
| On-board Storage | Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
| Alarm I/O | 1/1 |
| Wi-Fi parameters |
| Wi-Fi standard | IEEE802.11b, 802.11g, 802.11n Draft |
| Frequency range | 2.4 GHz ~ 2.4835 GHz |
Communication
bandwidth | Support 20/40 MHz |
| Protocols | 802.11b: CCK, QPSK, BPSK; 802.11g/n: OFDM |
| 802.11g/n: OFDM | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmission rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
| Transmission range | Outdoor: 200m, Indoor: 50m(depend on environment) |
| Wireless Standards | IEEE802.11b, 802.11g, 802.11n Draft |
| General |
| Working Temperature/Humidity | - -22 °F ~ 140 °F(-30 °C ~ 60 °C )
- Humidity 95% or less (non-condensing)
|
| Power Supply | DC12V±10% / PoE(802.3af) |
| Power Consumption | Max. 5W |
| PIR | - Angle: 80°
- Range: 33ft(10m)
|
| IR Range | 33ft(10m) |
| Dimension | 2.60"x3.60" x5.17"(66.0x91.5x131.3mm) |
| Weight | 0.9lbs(400g) |
