| Camera | - Image Sensor: 1/2.8" Progressive Scan CMOS
- Min. Illumination: Color 0.005 Lux @ (F1.6, AGC on), B/W 0 Lux with IR
- Shutter Speed: 1/3 to 1/100,000 sec.
- Slow Shutter: Yes
- P/N: P/N
- Wide Dynamic Range: 120 dB
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-90°, Rotate 0°-360°
|
| Lens | - Lens Type: Fixed focal lens, 2.8 mm
- Focal Length & FOV: Horizontal 107°, Vertical 57°, Diagonal 128°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.6
|
| DORI | - Detection (D): 88 m
- Observation (O): 35 m
- Recognition (R): 17 m
- Identification (I): 9 m
|
| Illuminator | - Supplemental Light Type: IR
- Smart Supplemental Lighting: Yes
- IR Wavelength: 850 nm
- IR Range: Up to 40 m
|
| Video | - Max. Resolution: 3840 × 2160
- Main Stream: 20 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream: 30 fps (640 × 480, 640 × 360)
- Third Stream: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Video Compression: H.265+ / H.265 / H.264+ / H.264 (Main), H.265 / H.264 / MJPEG (Sub), H.265 / H.264 (Third)
- Video Bit Rates: 32 Kbps to 16 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR / VBR
- Scalable Video Coding (SVC): H.264 and H.265
- Region of Interest (ROI): 1 fixed region for main and sub-stream
|
| Audio | - Audio Compression: G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
- Audio Bit Rates: 64 Kbps (G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 16-64 Kbps (AAC) / 32-192 Kbps (MP2L2) / 8-320 Kbps (MP3)
- Audio Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Environment Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, G), ISAPI, SDK
- User/Host: Up to 32 users (administrator, operator, user)
- Security: Password protection, HTTPS encryption, IP filter, Security Audit Log, basic/digest HTTP auth, TLS 1.1/1.2, WSSE
- Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- Client: NVMS V3, LTS-Connect, XVMS
- Web Browser: IE 10/11 (plug-in), Chrome 57+, Firefox 52+ (plug-in free & local service)
|
| Image | - Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- SNR: ≥ 52 dB
|
| Interface | - Ethernet: 1 RJ45 10/100 Mbps self-adaptive
- On-Board Storage: MicroSD up to 256 GB
- Built-in Microphone: Yes
- Reset Key: Yes
|
| Event | - Basic Events: Motion (human/vehicle), video tampering alarm, exceptions
- Face Detection: Yes
- Perimeter Protections: Line crossing, intrusion, human/vehicle classification
- Linkage Method: Upload to FTP/memory card/NAS, notify center, trigger recording/capture, send email
|
| General | - Materials: Aluminum alloy body, IR cover plastic
- Dimensions: Ø 70 × 161.7 mm (Ø2.8 × 6.4 in.)
- Package Dimensions: 216 × 121 × 118 mm (8.6 × 4.8 × 4.7 in.)
- Weight: 495 g (1.1 lbs), Package Weight: 759 g (1.7 lbs)
- Storage & Operating Conditions: -30° to 60°C (-22° to 140°F), humidity ≤95%
- General Function: Anti-flicker, heartbeat, password reset via email, pixel counter, software reset
- Firmware Version: V5.5.113
- Power: 12 VDC, 0.5 A, max 6 W; PoE 802.3af, max 7.2 W
- Power Supply: 12 VDC ±25%, reverse polarity protection; PoE Class 3
- Power Interface: Ø5.5 mm coaxial plug
|
| Certifications | - EMC: FCC, CE-EMC EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 50130-4:2011+A1:2014; RCM AS/NZS CISPR 32:2015; IC ICES-003 Issue 6; KC KN32/KN35
- Safety: UL 60950-1, CB IEC 60950-1, CE-LVD EN 60950-1, BIS IS 13252 (Part 1)
- Environmental: CE-RoHS, WEEE, Reach
- Protections: IP67 IEC 60529-2013
|
