| Camera | - Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2560 × 1440
- Min. Illumination: Color 0.005 Lux @ (F1.6, AGC on), B/W 0 Lux with IR
- Shutter Speed: 1/3 to 1/100,000 sec.
- Wide Dynamic Range: 120 dB
- Day & Night: IR Cut Filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-90°, Rotation 0°-360°
|
| Lens | - Lens Type: Varifocal, motor-driven, 2.8-12 mm
- Focal Length & Field of View: 2.8-12 mm (Horizontal 102°-31°, Vertical 55°-18°, Diagonal 122°-36°)
- Lens Mount: Ø 14
- Iris Type: Fixed
- Aperture: F1.6
|
| Illuminator | - IR Wavelength: 850 nm
- IR Range: Up to 164 ft (50 m)
|
| Video | - Main Stream:
- 50 Hz: 20 fps (2560 × 1440), 25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- 60 Hz: 20 fps (2560 × 1440), 30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- Sub-Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression:
- Main stream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: MJPEG / H.264 / H.265
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Region of Interest (ROI): 1 fixed region for main stream
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface, ISAPI
- User / Host: Up to 32 users (administrator, operator, user)
- Web Browser:
- Plug-in required: IE 10+
- Plug-in free: Chrome 57.0+, Firefox 52.0+
- Local service: Chrome 57.0+, Firefox 52.0+
|
| Imaging | - Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable via client or web browser
- Day / Night Switch: Auto, Schedule, Day, Night
- Image Enhancement: BLC, 3D DNR
|
| Interface | - Ethernet Interface: 1 RJ45 10/100 Mbps self-adaptive port
- On-Board Storage: MicroSD slot (up to 256 GB)
- Reset Key: Yes
|
| Event Types | - Basic Events: Motion detection, video tampering alarm, exception
- Linkage: Upload to FTP, notify surveillance center, send email, upload to memory card, trigger recording, trigger capture
|
| General | - Power: 12 VDC ±25%, 0.9 A, max. 11 W (Ø 5.5 mm coaxial plug)
- PoE: 802.3af Class 3, 36-57 V, max. 12.9 W
- Camera Materials: Metal
- Camera Dimensions: Ø 4.1 × 9.6 in. (Ø 105 × 244.4 mm)
- Package Dimensions: 12.4 × 5.4 × 5.6 in. (315 × 137 × 141 mm)
- Camera Weight: Approx. 2.3 lbs (1,035 g)
- Shipping Weight: Approx. 3.4 lbs (1,550 g)
- Storage Conditions: -22° to 140° F (-30° to 60° C); Humidity ≤95% (non-condensing)
- Startup & Operating Conditions: -22° to 140° F (-30° to 60° C); Humidity ≤95% (non-condensing)
- Language: English
- General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
| Certifications | - EMC: FCC SDoC, CE-EMC, RCM, IC VoC, KC
- Safety: UL, CB, CE-LVD, BIS
- Environmental: CE-RoHS, WEEE, Reach
- Electrical Safety Protections: IP67 (IEC 60529-2013)
|
