| Camera | - Image Sensor: 1/3" progressive scan CMOS
- Min. Illumination: Color: 0.01 Lux @(F2.0, AGC on), B/W: 0 Lux with IR
- Shutter Speed: 1/3 to 1/100,000 sec.
- Slow Shutter: Yes
- Wide Dynamic Range: 120 dB
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0° to 360°, tilt 0° to 180°, rotate 0° to 360°
|
| Lens | - Focal Length & FOV: 2.8 mm (Horizontal 98.0°, Vertical 53.1°, Diagonal 114.7°)
- Lens Mount: M12
- Focus: Fixed
- Aperture: F2.0
|
| Illuminator | - IR Wavelength: 850 nm
- IR Range: Up to 98 ft (30 m)
|
| Video | - Max. Resolution: 2560 × 1440
- Main Stream:
- 50 Hz: 20 fps (2560 × 1440), 25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- 60 Hz: 20 fps (2560 × 1440), 30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- Sub-Stream:
- 50 Hz: 25 fps (640 × 480, 640 × 360)
- 60 Hz: 30 fps (640 × 480, 640 × 360)
- Video Compression:
- Main stream: H.265 / H.264
- Sub-stream: H.265 / H.264 / MJPEG
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- H.264+: Main stream supported
- H.265+: Main stream supported
- Region of Interest (ROI): 1 fixed region for main stream
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface, ISAPI
- User / Host: Up to 32 users (administrator, operator, user)
- Network Storage: NAS (NFS, SMB / CIFS), ANR
- Web Browser:
- Plug-in required: IE 10+
- Plug-in free: Chrome 57.0+, Firefox 52.0+
- Local service: Chrome 57.0+, Firefox 52.0+
|
| Image | - Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable via client or web browser
- Day / Night Switch: Auto, Schedule, Day, Night
- Image Enhancement: BLC, 3D DNR
|
| Interface | - Ethernet Interface: 1 RJ45 10/100 Mbps self-adaptive port
- On-Board Storage: MicroSD slot (up to 256 GB)
- Built-in Microphone: Yes
- Hardware Reset: Yes
|
| Event Types | - Basic Events: Motion detection, video tampering alarm, exceptions / anomalies
|
| General | - Linkage Method: Upload to FTP, notify surveillance center, send email
- Also supports: Upload to memory card, trigger recording, trigger capture
- Camera Material: Metal & Plastic
- Camera Dimensions: 7.0 × 2.6 × 2.7 in. (177.6 × 66.2 × 67.8 mm)
- Package Dimensions: 8.5 × 4.8 × 4.6 in. (216 × 121 × 118 mm)
- Camera Weight: Approx. 0.6 lbs (270 g)
- Package Weight: Approx. 1.1 lbs (490 g)
- Storage Conditions: -22° to 140° F (-30° to 60° C), humidity ≤95% (non-condensing)
- Startup and Operating Conditions: -22° to 140° F (-30° to 60° C), humidity ≤95% (non-condensing)
- General Functions: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Power Consumption: 12 VDC, 0.4 A, max. 5 W; PoE (802.3af), max. 6.5 W
- Power Supply: 12 VDC ±25% / PoE 802.3af Class 3
- Power Interface: Ø 5.5 mm coaxial plug
|
| Certifications | - EMC: FCC SDoC, CE-EMC, RCM, IC VoC, KC
- Safety: UL, CB, CE-LVD, BIS
- Environmental: CE-RoHS, WEEE, Reach
- Protections: IP67 (IEC 60529-2013)
|
