| Camera |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 3840 × 2160 |
| Min. Illumination | Color: 0.0008 Lux @ f1.0, AGC on; 0 Lux with light |
| Shutter Speed | 1/3 to 1/100,000 sec. |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Lens |
| Lens Type | Fixed focal lens, 2.8 mm |
| Focal Length & FOV | 2.8 mm; horizontal: 105.1°; vertical: 54.8°; diagonal: 128.2° |
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | f1.0 |
| Depth of Field | 3.3 m to ∞ |
| DORI |
| Distance | D: 89 m, O: 35 m, R: 17 m, I: 8 m |
| Illuminator |
| Supplemental Light Types | IR, White |
| Supplemental Light Range | Up to 95 ft (30 m) |
| Smart Supplemental Light | Yes |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | - 24 fps (3840 × 2160)
- 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
| Sub-Stream | 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream | - 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Supported under certain settings
|
| Video Compression | - Main: H.264 / H.264+ / H.265 / H.265+
- Sub: H.264 / H.265 / MJPEG
- Third: H.264 / H.265
|
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline / Main / High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| SVC | H.264 and H.265 encoding |
| ROI | 1 fixed region for main and sub-stream |
| Audio |
| Audio Type | Mono |
| Audio Compression | G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711) / 16 Kbps (G.722.1, G.726) / 16-64 Kbps (AAC-LC) / 32-192 Kbps (MP2L2) / 8-320 Kbps (MP3) |
| Audio Sampling Rate | 8 / 16 / 32 / 44.1 / 48 kHz |
| Environmental Noise Filtering | Yes |
| Network |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Profile S/G/T), ISAPI, SDK, ISUP |
| User / Host | Up to 32 users (administrator, operator, user) |
| Security | - Password protection, HTTPS encryption
- 802.1X authentication (EAP-TLS, LEAP, MD5)
- IP filter, watermark
- Basic/Digest auth, WSSE
- TLS 1.1 / 1.2 / 1.3
- Security audit log
|
| Network Storage | NAS (NFS, SMB/CIFS), ANR, encrypted memory card support |
| Client | NVMS V3, LTS Connect, XVMS |
| Web Browsers | IE 10/11; Chrome 57+; Firefox 52+; Edge 89+ |
| Image |
| Image Parameters Switch | Yes |
| Image Enhancement | BLC, HLC, 3D DNR |
| SNR | ≥ 52 dB |
| WDR | 130 dB |
| Privacy Mask | 4 programmable polygon masks |
| Interface |
| Ethernet | 1 × RJ45 10/100 Mbps |
| Storage | MicroSD / SDHC / SDXC up to 512 GB |
| Built-in Microphone | Yes |
| Alarm | 1 input, 1 output (max 12 V DC, 30 mA) |
| Reset Key | Yes |
| Smart Functions |
| Face Capture | Yes |
| Perimeter Protection | Line crossing, intrusion, region entrance/exit (human/vehicle) |
| Scene Change Detection | Yes |
| General |
| Power | 12 V DC ±25%, max 8 W; PoE IEEE 802.3af, Class 3 |
| Material | Aluminum alloy |
| Dimensions | Ø 121.5 × 97.6 mm |
| Weight | Approx. 525 g |
| Operating Conditions | -30° to 60° C, ≤95% humidity |
| Protection | IP67, IK10 |
