| Camera |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.0028 Lux @ f1.2, AGC on; 0 Lux with supplemental visible light |
| Shutter Speed | 1/3 to 1/100,000 sec. |
| Day & Night | IR cut filter |
| Angle Adjustment | Remote adjustment (max 1,000 cycles), Pan: 0°-350°, Tilt: 0°-85°, Rotate: 0°-350° |
| Lens |
| Lens Type | Motorized varifocal lens, 2.8-12 mm |
| Focal Length & FOV | Horizontal FOV 114.6°-41.8°, Vertical FOV 59.3°-23.6°, Diagonal FOV 141.3°-48.1° |
| Lens Mount | Integrated |
| Iris Type | Fixed |
| Aperture | Up to 1.2 |
| Depth of Field | 1 m to ∞ |
| Detect, Observe, Recognize, Identify |
| Ranges (Approx.) | - Wide: D: 200 ft (61.5 m), O: 80 ft (24.4 m), R: 40 ft (12.3 m), I: 20 ft (6.2 m)
- Tele: D: 495 ft (151.7 m), O: 195 ft (60.2 m), R: 100 ft (30.3 m), I: 50 ft (15.1 m)
|
| Supplemental Lighting |
| Type | IR, Visible (White) |
| Range | Up to 130 ft |
| Technology | Smart Hybrid |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | 30 fps (2688×1520, 1920×1080, 1280×720) |
| Sub-Stream | 30 fps (1280×720, 640×480, 640×360) |
| Third Stream | - 10 fps (1920×1080, 1280×720, 640×480, 640×360)
- *Third stream supported under certain settings
|
| Video Compression | - Main stream: H.265 / H.264 / H.264+ / H.265+
- Sub-stream: H.265 / H.264 / MJPEG
- Third stream: H.265 / H.264
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline, Main, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| SVC | H.264 and H.265 encoding |
| ROI | 1 fixed region for main and sub-stream |
| Audio |
| Audio Compression | G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711 ulaw/alaw), 16 Kbps (G.722.1/G.726), 32-192 Kbps (MP2L2), 8-320 Kbps (MP3), 16-64 Kbps (AAC-LC) |
| Audio Sampling Rates | 8 / 16 / 32 / 44.1 / 48 kHz |
| Environmental Noise Filtering | Yes |
| Network |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF Profile S/G/T |
| User / Host | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security | - Password protection, complicated password
- HTTPS encryption
- 802.1X (EAP-TLS, LEAP, MD5)
- Watermark, IP filter
- Basic/digest authentication for HTTP/HTTPS, WSSE
- RTP/RTSP over HTTPS, control timeout, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC)
|
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Client | LTS Connect |
| Web Browsers | - Plug-in required: IE 11
- Plug-in free: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
- Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
|
| Imaging |
| Image Parameters Switching | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client/browser |
| Day / Night Switching | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| SNR | ≥ 52 dB |
| WDR | 120 dB |
| Privacy Mask | 4 programmable polygon privacy masks |
| Interface |
| Ethernet Interface | 1 x RJ45 10/100 Mbps self-adaptive |
| On-Board Storage | MicroSD / SDHC / SDXC up to 512 GB |
| Built-in Microphone | 2 microphones |
| Built-in Speaker | 1 speaker, max power 2 W, 10 cm: 97 dB |
| Audio | - 1 input (line in), two-core terminal, max 3.3 Vpp, impedance 4.7 kΩ
- 1 output (line out), two-core terminal, max 3.3 Vpp, impedance 100 Ω
|
| Alarm | 1 input, 1 output (max 24 V DC / 24 V AC, 1 A) |
| Reset Key | Yes |
| Event Types |
| Basic | Motion detection (support alarm triggering by human/vehicle), video tampering alarm, exception |
| Smart | Scene change detection |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, trigger recording/capture, send email, audible warning, trigger alarm output, white light flashing |
| Deep Learning Functions |
| Face Capture | Yes |
| Perimeter Protection | Line crossing, intrusion, region entrance/exiting, support alarm triggering by human/vehicle |
| General |
| Power | 12 VDC ±25%, 1.35 A, max 16 W, reverse polarity protection, PoE: IEEE 802.3at, Class 4, max 18 W |
| Materials | Metal |
| Dimensions | Ø 6.10" × 5.23" (Ø 155 × 140.4 mm) |
| Package Dimensions | 8.1 × 8.1 × 9.1" (206 × 206 × 230 mm) |
| Weight | Approx. 1.8 lb (820 g) |
| Packaged Weight | Approx. 2.6 lb (1,200 g) |
| Storage Conditions | -22° to 140° F (-30° to 60° C), Humidity ≤95% non-condensing |
| Startup / Operating Conditions | -22° to 140° F (-30° to 60° C), Humidity ≤95% non-condensing |
| General Functions | Heartbeat, mirror, password reset via email, pixel counter, anti-banding, flash log |
| Strobe | White Flashing Light |
