| Camera |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1/3 sec. to 1/100,000 sec. |
| Angle Adjustment | Pan: 0°-355°, Tilt: 0°-75°, Rotate: 0°-355° |
| Day & Night | 24/7 color imaging |
| Lens |
| Lens Type | Varifocal, motorized, 2.8-12 mm |
| Focal Length & FOV | 2.8-12 mm; horizontal 105.4°-56.4°, vertical 53.9°-31.6° |
| Lens Mount | Integrated |
| Iris Type | DC iris |
| Aperture | F1.0 |
| Depth of Field | 1.9 m to ∞ |
| Detection, Observation, Recognition, Identification |
| DORI | D: 66.8-110.4 m, O: 26.5-43.8 m, R: 13.4-22.1 m, I: 6.7-11 m |
| Illuminator |
| Supplemental Light Type | White Light |
| Supplemental Light Range | Up to 40 m |
| Smart Supplemental Lighting | Yes |
| Video |
| Main Stream | 30 fps (2688×1520, 1920×1080, 1280×720) |
| Sub-Stream | 30 fps (1280×720, 640×480, 640×360) |
| Third Stream | - 10 fps (1920×1080, 1280×720, 640×480, 640×360)
- *Third stream is supported under certain settings
|
| Video Compression | - Main stream: H.265 / H.264 / H.265+ / H.264+
- Sub-stream: H.265 / H.264 / MJPEG
- Third stream: H.265 / H.264
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline, Main, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | VBR, CBR |
| SVC | H.264 and H.265 encoding |
| ROI | 1 fixed region(s) for main stream and sub-stream |
| Audio |
| Audio Compressions | G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC |
| Audio Bit Rates | 64 Kbps (G.711 ulaw/alaw), 16 Kbps (G.722.1), 16 Kbps (G.726), 32-192 Kbps (MP2L2), 8-320 Kbps (MP3), 16-64 Kbps (AAC-LC) |
| Audio Sampling Rates | 8 / 16 / 32 / 44.1 / 48 kHz |
| Environmental Noise Filtering | Yes |
| Network |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF Profile S/G/T, ISAPI, SDK |
| User/Host | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security | - Password protection, complicated password
- HTTPS encryption
- 802.1X (EAP-TLS, LEAP, MD5)
- Watermark, IP filter
- Basic/digest auth for HTTP/HTTPS, WSSE
- RTP/RTSP over HTTPS, Control Timeout, Security Audit Log, TLS 1.1/1.2/1.3, host authentication (MAC)
|
| Network Storage | NAS (NFS, SMB/CIFS), ANR, Hikvision memory card support with encryption |
| Client | LTS Connect, NVMS, X-VMS |
| Web Browser | - Plug-in required: IE 10, 11
- Plug-in free: Chrome 57+, Firefox 52+, Edge 89+
- Local service: Chrome 57+, Firefox 52+, Edge 89+
|
| Image |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client/browser |
| Day / Night Switch | Day, Night, Auto, Schedule |
| WDR | 130 dB |
| SNR | ≥ 52 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
| Privacy Mask | 4 regions of privacy mask |
| Interface |
| Ethernet | 1 x RJ45 10/100 M self-adaptive |
| On-Board Storage | MicroSD / SDHC / SDXC up to 512 GB |
| Audio | - 1 input (line in), 2-core terminal, max 3.3 Vpp, impedance 4.7 KΩ
- 1 output (line out), 2-core terminal, max 3.3 Vpp, impedance 100 Ω
|
| Alarm | 1 input, 1 output (max. 24 VDC / 24 VAC, 1 A) |
| Reset Key | Yes |
| Event Types |
| Basic Events | Motion detection (support alarm triggering by specified target types: human/vehicle), video tampering alarm, network disconnected, IP conflict, illegal login, HDD full/error |
| Smart Events | Line crossing, intrusion, region entrance/exiting, scene change (support alarm triggered by human/vehicle) |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, trigger recording/capture, send email, trigger alarm output, white light flashing |
| Other VCA Function | Face Capture: Yes |
| General |
| Power | - 12 VDC ±25%, 0.9 A, max 10.8 W, Ø5.5 mm coaxial, reverse polarity protection
- PoE: 802.3af, Class 3, 36-57 V, 0.36-0.23 A, max 12.9 W
|
| Dimensions | Ø 6.1" × 6.0" |
| Package Dimensions | 8.9 × 7.8 × 8.7 in. |
| Weight | Approx. 3.4 lbs |
| Package Weight | Approx. 4.6 lbs |
| Storage Conditions | -22° to 140° F, Humidity ≤95% non-condensing |
| Startup / Operating Conditions | -22° to 140° F, Humidity ≤95% non-condensing |
| General Function | Heartbeat, anti-banding, mirror, flash log, password reset via email, pixel counter |
| Certifications |
| EMC | FCC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032/61000-3-2/3, EN 50130-4; RCM: AS/NZS CISPR 32; IC: ICES-003; KC: KN32, KN35 |
| Safety | UL: UL 62368-1; CB: IEC 62368-1:2014+A11; CE-LVD: EN 62368-1:2014/A11; LOA: IEC/EN 60950-1 |
| Environmental | CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) 1907/2006 |
| Protections | IP67: IEC 60529-2013; IK10: IEC 62262:2002 |
