| Camera |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1/3 sec. to 1/100,000 sec. |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0°-355°, Tilt: 0°-75°, Rotate: 0°-355° |
| Lens |
| Lens Type | Fixed focal lens, 2.8 mm |
| Field of View | Horizontal 100.2°, Vertical 54.7°, Diagonal 119.7° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | 1.9 m to ∞ |
| Detection, Observation, Recognition, Identification |
| DORI | D: 63 m, O: 25 m, R: 12 m, I: 6 m |
| Illuminator |
| Supplemental Light Type | IR, White Light |
| Supplemental Light Range | Up to 40 m |
| Smart Supplemental Lighting | Yes |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | 30 fps (2688×1520, 1920×1080, 1280×720) |
| Sub-Stream | 30 fps (1280×720, 640×480, 640×360) |
| Third Stream | - 10 fps (1920×1080, 1280×720, 640×480, 640×360)
- *The third stream is supported under certain settings
|
| Video Compression | - Main stream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: H.265 / H.264 / MJPEG
- Third stream: H.265 / H.264
- *The third stream is supported under certain settings
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline, Main, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| SVC | H.264 and H.265 encoding |
| ROI | 1 fixed region for main and sub-stream |
| Audio |
| Audio Compression | G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC |
| Audio Bit Rate | 64 Kbps(G.711 ulaw/alaw), 16 Kbps(G.722.1), 16 Kbps(G.726), 16-64 Kbps(AAC-LC), 32-192 Kbps(MP2L2), 8-320 Kbps(MP3) |
| Audio Sampling Rates | 8 / 16 / 32 / 44.1 / 48 kHz |
| Environmental Noise Filtering | Yes |
| Network |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF Profile S/G/T, ISAPI, SDK, ISUP |
| User / Host | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security | - Password protection, complicated password
- HTTPS encryption
- 802.1X (EAP-TLS, LEAP, MD5)
- Watermark, IP filter
- Basic/digest auth for HTTP/HTTPS, WSSE
- RTP/RTSP over HTTPS, Control Timeout, Security Audit Log, TLS 1.1/1.2/1.3, host authentication (MAC)
|
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Client | LTS Connect, NVMS, X-VMS |
| Web Browser | - Plug-in required: IE 10, 11
- Plug-in free: Chrome 57+, Firefox 52+, Edge 89+
- Local service: Chrome 57+, Firefox 52+, Edge 89+
|
| Image |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable via client/browser |
| Day / Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| SNR | ≥ 52 dB |
| WDR | 120 dB |
| Privacy Mask | 4 programmable polygon masks |
| Interface |
| Ethernet | 1 x RJ45 10/100 Mbps self-adaptive |
| On-Board Storage | MicroSD / SDHC / SDXC up to 512 GB |
| Built-in Microphone | Yes |
| Audio | - 1 input (line in), 2-core terminal, max 3.3 Vpp, impedance 4.7 KΩ
- 1 output (line out), 2-core terminal, max 3.3 Vpp, impedance 100 Ω
|
| Alarm | 1 input, 1 output (max 12 VDC, 30 mA) |
| Reset Key | Yes |
| Event Types |
| Basic Events | Motion detection (support alarm triggering by specified target types: human/vehicle), video tampering alarm, anomalies |
| Smart Events | Line crossing, intrusion, region entrance/exiting, scene change (support alarm triggering by human/vehicle) |
| Other VCA Functions | Face Capture Yes |
| General |
| Power | - 12 VDC ±25%, 0.6 A, max 7.2 W, Ø5.5 mm coaxial, reverse polarity protection
- PoE: IEEE 802.3 af, Class 3, max 8.5 W
|
| Material | Metal |
| Camera Dimensions | Ø 4.8 × 3.8 in. |
| Package Dimensions | 5.9 × 5.9 × 5.6 in. |
| Weight | Approx. 1.2 lbs |
| Package Weight | Approx. 1.8 lbs |
| Storage Conditions | -22°F to 140°F, Humidity ≤95% non-condensing |
| Startup / Operating Conditions | -22°F to 140°F, Humidity ≤95% non-condensing |
| General Function | Heartbeat, mirror, password reset via email, pixel counter, anti-banding |
| Certifications |
| EMC | CE-EMC: EN 55032, EN 61000-3-2/3, EN 50130-4; FCC: 47 CFR Part 15 |
| Safety | UL 62368-1, CB IEC 62368-1, CE-LVD EN 62368-1 |
| Environmental | CE-RoHS 2011/65/EU |
| Protections | IP67 IEC 60529-2013; IK10 IEC 62262:2002 |
