| Camera |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | - Color: 0.0005 Lux @ (F1.2, AGC on)
- B & W: 0.0001 Lux @ (F1.2, AGC on)
- 0 Lux with IR
|
| Shutter Time | 1 sec. to 1/100,000 sec. |
| Day & Night | - IR cut filter
- Blue glass module to reduce ghost phenomenon
|
| Lens |
| Field of View | Horizontal: 42.5°-15.1°, Vertical: 23.3°-8.64°, Diagonal: 49.6°-17.3° |
| Focus | Auto, semi-auto, manual |
| Iris Type | P-iris |
| Aperture / Focal Length | 8 to 32 mm: F1.7 to F1.73 |
| Detection, Observation, Recognition, Identification |
| DORI | - 8 mm: D 150.3 m, O 59.7 m, R 30.1 m, I 15 m
- 32 mm: D 400 m, O 158.7 m, R 80 m, I 40 m
|
| Illuminator |
| Supplemental Light Type | IR |
| Supplemental Light Range | 100 m |
| Smart Supplemental Lighting | Yes |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | 30 fps (2688×1520, 2560×1440, 1920×1080, 1280×720) |
| Sub-Stream | 30 fps (704×480, 640×480) |
| Third Stream | 30 fps (1920×1080, 1280×720, 704×480, 640×480) |
| Fourth Stream | 30 fps (1920×1080, 1280×720, 704×480, 640×480) |
| Fifth Stream | 30 fps (704×480, 640×480) |
| Video Compression | - Main stream: H.265+ / H.265 / H.264+ / H.264
- Sub / Third / Fourth / Fifth streams: H.265 / H.264 / MJPEG
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline / Main / High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR / VBR |
| Scalable Video Coding (SVC) | H.265 and H.264 encoding |
| ROI | 4 fixed regions per stream |
| Target Cropping | Yes |
| Network |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Simultaneous Live View | Up to 20 channels |
| API | ONVIF Profile S/G/T, ISAPI, SDK, ISUP |
| User / Host | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security | - Password protection, complicated password
- HTTPS encryption
- 802.1X (EAP-TLS, LEAP, MD5)
- Watermark, IP filter
- Basic/digest auth for HTTP/HTTPS, WSSE
- RTP/RTSP over HTTPS, Control Timeout, Security Audit Log, TLS 1.2
|
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Client | NVMS V3, LTS-Connect, X-VMS |
| Web Browser | - Plug-in required: IE 8+
- Plug-in free: Chrome 57+, Firefox 52+, Safari 11+
- Local service: Chrome 41+, Firefox 30+
|
| Image |
| Image Parameters Switch | Yes |
| Image Settings | Saturation, brightness, contrast, sharpness, gain, white balance adjustable via client/browser |
| Day / Night Switch | Day, Night, Auto, Schedule, Alarm/Video Trigger |
| WDR | 140 dB |
| SNR | ≥52 dB |
| Image Enhancement | BLC, HLC, Defog, 3D DNR |
| Picture Overlay | Logo overlay 128×128, 24-bit .bmp |
| Image Stabilization | EIS |
| Interface |
| Video Output | 1 Vp-p Composite Output (75 Ω/CVBS) (Debug only) |
| Ethernet | 1 RJ45 10/100/1000 M self-adaptive |
| On-Board Storage | MicroSD / SDHC / SDXC up to 256 GB |
| Alarm | 2 inputs, 2 outputs (max 24 VDC, 1 A) |
| Reset Key | Yes |
| Event Types |
| Basic Events | Motion detection, video tampering, network disconnected, IP conflict, illegal login, abnormal reboot, HDD full/error, video quality diagnosis, vibration detection |
| Smart Events | Intrusion, scene change, audio exception, defocus, line crossing (up to 4 lines), intrusion detection (up to 4 regions), region entrance/exiting (up to 4 regions) |
| Linkage | Upload to FTP/NAS/memory card, notify center, email, trigger alarm, recording, capture |
| Deep Learning Functions |
| Perimeter Protections | Line crossing, intrusion, region entrance, region exit, supports alarm for specified target types |
| Road Traffic / Vehicle Detections | - Block/allow lists up to 10,000 records
- Capture vehicle without license plate
- License plate recognition for motorcycles (checkpoint scenario)
- Vehicle attributes: type, color, brand (City Street mode recommended)
- Metadata of road traffic supported
|
| General / Power |
| Power | - 12 VDC ±20%, 1.19 A, max 14.28 W, three-core terminal
- PoE: 802.3at, Type 2, Class 4, 42.5-57 V, 0.396-0.295 A, max 16.8 W
|
| Material | Aluminum alloy body |
| Dimensions | Ø140 × 351 mm (Ø5.5 × 13.8 in.) |
| Package Dimensions | 405 × 190 × 180 mm (15.9 × 7.5 × 7.1 in.) |
| Weight | Approx. 1,950 g (4.2 lbs) |
| Package Weight | Approx. 3,070 g (6.7 lbs) |
| Storage Conditions | -30° to 60° C, Humidity ≤95% non-condensing |
| Startup / Operating Conditions | -40° to 60° C, Humidity ≤95% non-condensing |
| General Functions | Anti-flicker, 5 streams, EPTZ, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Certifications / Environmental |
| EMC | FCC (47 CFR Part 15, Subpart B), CE-EMC (EN 55032:2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014), RCM (AS/NZS CISPR 32:2015), IC (ICES-003 Issue 7), KC (KN32/35:2015) |
| Safety | UL (UL 62368-1), CB (IEC 62368-1:2014+A11), CE-LVD (EN 62368-1:2014/A11:2017), BIS (IS 13252 Part1/IEC60950-1), LOA (IEC/EN60950-1) |
| Environmental | CE-RoHS, WEEE, REACH |
| Protections | IK10 (IEC62262:2002), IP67 (IEC60529:2013), Automotive & Railway EN50121-4 |
| Other | PVC FREE |
