| Camera |
| Image Sensor | Varifocal: 1/2.4" Progressive Scan CMOS; Fixed: 1/2.5" Progressive Scan CMOS |
| Max. Resolution | 4 @ 2560 × 1920 and 1 @ 1440 × 1440 |
| Min. Illumination | - Color: 0.005 Lux @ (F1.2, AGC ON)
- B/W: 0.002 Lux @ (F1.2, AGC ON)
- B/W: 0 Lux with IR
|
| Shutter Time | 1 to 1/100,000 sec. |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0°-350°, Tilt: 0°-90°, Rotate: -90°-90° |
| Lens |
| Lens Type | 4 × Varifocal motorized lenses: 2.8-8 mm; 1 × Fixed focal lens: 2 mm |
| Focal Lengths & FOV | - Varifocal: H 96.5°-48.9°, V 69.9°-36.5°, D 129°-61.3°
- Fixed: H 71.68°, V 71.68°, D 99.16°
|
| Lens Mount | Ø14 |
| Focus | Varifocal: Semi-auto, Manual |
| Aperture | Varifocal: 1.9 | Fixed: 2.25 |
| Supplemental Lighting |
| Type | IR |
| Range | Up to 110 ft |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | - Channels 1-4: 30 fps (2560×1920, 2048×1536, 1920×1080, 1280×720)
- Channel 5: 30 fps (1440×1440)
|
| Sub-Stream | - Channels 1-4: 30 fps (704×480, 640×480)
- Channel 5: 30 fps (576×576, 480×480)
|
| Third Stream | Channels 1-4: 30 fps (1920×1080, 1280×720, 704×576, 640×480) |
| Video Compression | - Main stream: H.265+ / H.265 / H.264+ / H.264
- Sub-stream: H.265 / H.264 / MJPEG
- Third stream: H.265 / H.264
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline, Main, High Profile |
| H.265 Type | Main Profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| ROI | 4 fixed regions per stream |
| Target Cropping | Yes |
| Audio |
| Audio Compressions | G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC |
| Audio Bit Rates | - 64 Kbps (G.711 ulaw/alaw)
- 16 Kbps (G.722.1 / G.726)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- 16-64 Kbps (AAC-LC)
|
| Audio Sampling Rates | 8 / 16 / 32 / 48 kHz |
| Environmental Noise Filtering | Yes |
| Network |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, WebSocket, WebSockets, SSL/TLS |
| Simultaneous Live View | Up to 20 channels |
| API | ONVIF (Profile S, G, T), ISAPI, SDK, ISUP |
| User / Host | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security | - Password protection, complicated password
- HTTPS encryption
- 802.1X authentication (EAP-MD5)
- Watermark, IP filter
- Basic/digest authentication for HTTP/HTTPS
- WSSE/digest authentication for ONVIF
|
| Network Storage | NAS (NFS, SMB/CIFS), ANR, memory card with encryption & health detection |
| Client | Guarding Vision |
| Web Browsers | - Plug-in required: IE 10, IE 11
- Plug-in free: Chrome 57+, Firefox 52+, Edge 89+, Safari 11+
- Local service: Chrome 57+, Firefox 52+, Edge 89+
|
| Imaging |
| Image Settings | Rotate, saturation, brightness, contrast, sharpness, AGC, white balance (adjustable via client/browser) |
| Day / Night Switching | Day, Night, Auto, Schedule, Alarm Trigger |
| WDR | 120 dB |
| SNR | ≥52 dB |
| Image Stabilization | EIS |
| Image Enhancement | BLC, HLC, 3D DNR, Defog |
| Privacy Mask | 8 programmable polygon masks |
| Picture Overlay | 1 logo image, 128×128 24-bit .bmp |
| Interface |
| Ethernet | 1 × RJ45 10/100/1000 Mbps |
| On-Board Storage | MicroSD / SDHC / SDXC up to 1 TB |
| Audio | 1 × input (line in), 1 × output (line out), 3.5 mm connectors |
| Alarm | 2 inputs, 2 outputs (max 24 VDC, 1 A) |
| RS-485 | 1 × RS-485 (Half duplex, Pelco-P/D, self-adaptive) |
| Reset Key | Yes |
| Events |
| Basic | Motion detection, video tampering, network disconnect, IP conflict, illegal login, HDD full/error |
| Smart | Line crossing, intrusion, region entrance/exiting, scene change, unattended baggage, object removal |
| Linkage | Upload to FTP/NAS/memory card, notify center, email, trigger alarm, recording, capture |
| Deep Learning Functions | - Perimeter Protections: Line crossing, intrusion, region entrance/exiting
- Supports alarm triggering for humans and vehicles
|
| General / Power |
| Power | - 12 V DC ±20%, 1.8 A, max 21.6 W
- PoE: IEEE 802.3at, Type 2, Class 4, 42.5-57 V, 0.58-0.43 A, max 25 W
|
| Dimensions | Ø290 × 148 mm (Ø11.42 × 5.8") |
| Shipping Dimensions | 453 × 393 × 385 mm (17.8 × 15.47 × 15.16") |
| Weight | Approx. 4.7 kg (10.36 lb.) |
| Shipping Weight | Approx. 8.0 kg (17.63 lb.) |
| Storage Conditions | -40° to 60° C, Humidity ≤95% (non-condensing) |
| Startup / Operating Conditions | -40° to 60° C, Humidity ≤95% (non-condensing) |
| General Functions | Heartbeat, flash log, password reset via email, pixel counter, password protection, one-key reset, anti-banding |
| Certifications / Protection |
| Protection Ratings | IP67: IEC 60529-2013 | IK10: IEC 62262:2002 |
