| Camera |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Max. Resolution | 2560 × 1920 |
| Min. Illumination | - Color: 0.0125 Lux @ (F1.9, AGC on)
- B/W: 0.0025 Lux @ (F1.9, AGC on), 0 Lux with IR
|
| Shutter Time | 1 sec. to 1/100,000 sec. |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: -60° to 60°, Tilt: 10° to 90°, Rotate: 0° to 350° |
| Lenses |
| Lens Type | Varifocal, motorized lenses, 2.8 to 8 mm |
| Focal Length & FOV | 2.8 to 8 mm; FOV:- Horizontal: 100° to 49°
- Vertical: 72° to 36.4°
- Diagonal: 134.4° to 61.4°
|
| Lens Mount | Ø 14 |
| Focus | Semi-auto, Manual |
| Aperture | F1.9 |
| Illuminator |
| Supplement Light Type | IR |
| Supplement Light Range | Up to 98 ft (30 m) |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | 15 fps (2560 × 1920, 2048 × 1536, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 15 fps (704 × 480, 640 × 480) |
| Third Stream | 8 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Video Compressions | - Main stream: H.265+ / H.265 / H.264+ / H.264
- Sub-stream: H.265 / H.264 / MJPEG
- Third stream: H.265 / H.264
|
| Video Bit Rates | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline, Main, High Profile |
| H.265 Type | Main Profile |
| Scalable Video Coding (SVC) | H.264 encoding |
| Region of Interest (ROI) | 4 fixed regions per stream |
| Target Cropping | Yes |
| Audio |
| Audio Compressions | G.711 / G.722.1 / G.726 / MP2L2 / PCM |
| Audio Bit Rates | - 64 Kbps (G.711)
- 16 Kbps (G.722.1 / G.726)
- 32-192 Kbps (MP2L2)
- 32 Kbps (PCM)
|
| Audio Sampling Rates | 8, 16, 32, 44.1, 48 kHz |
| Environmental Noise Filtering | Yes |
| Network |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Simultaneous Live View | Up to 20 channels |
| API | ONVIF (Profile S, G, T), ISAPI, SDK |
| User / Host | Up to 32 users, 3 levels: administrator, operator, user |
| Security | - Password protection, complicated password
- HTTPS encryption
- 802.1X (EAP-MD5) authentication
- Watermark, IP address filter
- Basic & digest authentication for HTTP/HTTPS
- WSSE & digest authentication for ONVIF
|
| Network Storage | NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| Client | NVMS V3, LTS Connect, XVMS |
| Web Browser | Internet Explorer 8+, Chrome 41-44, Firefox 30-51, Safari 8-11 |
| Image |
| Image Settings | Rotate, saturation, brightness, contrast, sharpness, AGC, white balance (adjustable via client/browser) |
| Day / Night Switch | Day, Night, Auto, Schedule, Alarm Trigger |
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Image Stabilization | EIS |
| Image Enhancement | BLC, HLC, 3D DNR, Defog |
| Picture Overlay | LOGO picture can be overlaid (128 × 128 24-bit .bmp) |
| Interface |
| Ethernet | 1 × RJ45 10/100/1000 M |
| On-board Storage | microSD / microSDHC / microSDXC up to 128 GB |
| Audio | 1 × input (line in), 1 × output (line out), 3.5 mm |
| Alarm | 2 × inputs, 2 × outputs (max 24 VDC, 1 A) |
| RS-485 | 1 × RS-485 (half duplex, Hikvision, Pelco-P/D, self-adaptive) |
| Reset Key | Yes |
| Events |
| Basic Events | Motion detection, video tampering, exceptions (network disconnected, IP conflict, illegal login, HDD full/error) |
| Smart Events | - Line crossing detection
- Intrusion detection
- Region entrance/exiting detection
- Unattended baggage detection
- Object removal detection
- Scene change detection
- Audio anomaly detection
- Defocus detection
|
| Linkage | Upload to FTP/NAS/memory card, notify center, send email, trigger alarm, recording, capture |
| General / Power |
| Power | - 12 VDC ±20%, 1.8 A, 22 W, reverse polarity protection
- 24 VAC ±20%, 1.4 A, 22 W
- PoE: IEEE 802.3 at, Class 4, 42.5-57 VDC, 0.44-0.33 A, 19 W
|
| Materials | Bubble & IR cover: plastic, camera: metal |
| Dimensions | Ø250 × 114.9 mm (Ø9.8 × 4.5 in.) |
| Package Dimensions | 336 × 261 × 293 mm (13.2 × 10.3 × 11.5 in.) |
| Weight | Approx. 2.2 kg (4.9 lbs) |
| Package Weight | Approx. 3.9 kg (8.6 lbs) |
| Storage Conditions | -30° to 60°C, Humidity ≤95% (non-condensing) |
| Startup / Operating Conditions | -30° to 60°C, Humidity ≤95% (non-condensing) |
| General Functions | Anti-banding, heartbeat, mirror, privacy mask |
| Certifications / Safety / Environmental |
| EMC | - CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
- RCM: AS/NZS CISPR 32: 2015
- IC: ICES-003: Issue 7
- KC: KN32/KN35: 2015
|
| Safety | - UL: UL 62368-1
- CB: IEC 62368-1:2014+A11
- CE-LVD: EN 62368-1:2014/A11:2017
|
| Environmental | CE-RoHS: 2011/65/EU |
| Protection Ratings | IP67: IEC 60529-2013, IK10: IEC 62262:2002 |
