| Camera |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on |
| Shutter Speed | 1/3 to 1/100,000 sec. |
| Slow Shutter | Yes |
| P/N | P/N |
| Wide Dynamic Range | 120 dB |
| Day & Night | ICR Cut |
| Angle Adjustment | Pan: 0°-355°, Tilt: 0°-75°, Rotate: 0°-355° |
| Lens |
| Lens Type & FOV | - 2.8 mm: H 103°, V 55°, D 122°
- 4 mm: H 84°, V 45°, D 100°
|
| Aperture | F1.6 |
| Lens Mount | M12 |
| DORI |
| Detection / Observation / Recognition / Identification | - 2.8 mm: D 67 m, O 26 m, R 13 m, I 6 m
- 4 mm: D 80 m, O 31 m, R 16 m, I 8 m
|
| Illuminator |
| IR Range | Up to 98 ft (30 m) |
| Wavelength | 850 nm |
| Video |
| Max. Resolution | 2688 × 1520 |
| Main Stream | - 50Hz: 25 fps (2688×1520, 1920×1080, 1280×720)
- 60Hz: 30 fps (2688×1520, 1920×1080, 1280×720)
|
| Sub Stream | - 50Hz: 25 fps (640×480, 640×360)
- 60Hz: 30 fps (640×480, 640×360)
|
| Third Stream | - 50Hz: 25 fps (1280×720, 640×480, 640×360)
- 60Hz: 30 fps (1280×720, 640×480, 640×360)
|
| Video Compression | - Main: H.264 / H.264+ / H.265 / H.265+
- Sub: MJPEG / H.264 / H.265
- Third: H.264 / H.265
|
| Video Bit Rate | 32 Kbps - 8 Mbps |
| H.264 Type | Baseline / Main / High Profile |
| H.265 Type | Main Profile |
| H.264+ / H.265+ | Main Stream |
| Bit Rate Control | CBR / VBR |
| Scalable Video Coding (SVC) | Yes |
| ROI | 1 fixed region (main & sub-stream) |
| Audio |
| Environmental Noise Filtering | Yes |
| Sampling Rate | 8 / 16 / 32 / 44.1 / 48 kHz |
| Compression | G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC |
| Audio Bit Rate | - 64 Kbps (G.711 ulaw / alaw)
- 16 Kbps (G.722.1 / G.726)
- 16-64 Kbps (AAC)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
|
| Network |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (Profile S, G), ISAPI, SDK |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE |
| User / Host | Up to 32 users (administrator, operator, user) |
| Security | - Password protection, complicated password
- HTTPS encryption
- IP address filter
- Security Audit Log
- Basic/digest authentication for HTTP/HTTPS
- TLS 1.1 / 1.2
- WSSE and digest authentication for ONVIF
|
| Network Storage | MicroSD / SDHC / SDXC (up to 256 GB), NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Web Browsers | - Plug-in required: IE 10, IE 11
- Plug-in free: Chrome 57+, Firefox 52+
- Local service: Chrome 57+, Firefox 52+
|
| Imaging |
| Day / Night Switching | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Parameter Switching | Yes |
| Image Settings | Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance (adjustable via client or web) |
| Interface |
| Built-in Microphone | Yes |
| On-board Storage | MicroSD up to 256 GB |
| Hardware Reset | Yes |
| Communication Interface | 1 × RJ45 10/100 Mbps |
| Event Types |
| Basic Events | Motion detection (human/vehicle), video tampering, exceptions/anomalies |
| Face Detection | Yes |
| Deep Learning Functions | - Perimeter Protections
- Line crossing detection
- Intrusion detection
- Human and vehicle classification
|
| General |
| Linkage Methods | Upload to FTP / memory card / NAS, notify center, trigger record/capture, Email |
| Web Client Languages | - English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak
- French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish
- Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
|
| General Functions | Anti-flicker, heartbeat, password reset via e-mail, pixel counter |
| Storage Conditions | -30°C to 60°C, Humidity ≤95% |
| Startup & Operating Conditions | -30°C to 60°C, Humidity ≤95% |
| Power Supply |
| Voltage | 12 VDC ±25%, reverse polarity protection |
| PoE | 802.3af, Class 3 |
| Power Consumption & Current | - 12 VDC: 0.4 A, max 5 W
- PoE: 36-57 V, 0.2-0.15 A, max 6.5 W
|
| Power Interface | Ø 5.5 mm coaxial plug |
| Materials & Dimensions |
| Materials | Aluminum alloy body, plastic bubble |
| Camera Dimensions | Ø121.4 × 92.2 mm |
| Package Dimensions | 150 × 150 × 141 mm |
| Camera Weight | Approx. 570 g |
| Package Weight | Approx. 806 g |
| Certifications |
| EMC | - FCC (47 CFR Part 15, Subpart B)
- CE-EMC (EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 50130-4:2011 +A1:2014)
- RCM (AS/NZS CISPR 32:2015)
- IC (ICES-003: Issue 6, 2016)
- KC (KN 32:2015, KN 35:2015)
|
| Safety | - UL (UL 60950-1)
- CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013)
- CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
- BIS (IS 13252(Part 1):2010 +A1:2013 +A2:2015)
|
| Environmental | - CE-RoHS (2011/65/EU)
- WEEE (2012/19/EU)
- Reach (Regulation (EC) No 1907/2006)
|
| Protections | IP67 (IEC 60529-2013), IK10 (IEC 62262:2002) |
