| Camera | - Image Sensor: 1/2.8" Progressive Scan CMOS
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC on), B/W: 0 Lux with IR
- Shutter Speed: 1/3 to 1/100,000 sec.
- Slow Shutter: Yes
- P/N: P/N
- Wide Dynamic Range: 120 dB
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355°
|
| Lens | - Lens Type: Varifocal, motorized, 2.8 to 12 mm
- FOV: Horizontal 108° to 30°, Vertical 56° to 17°, Diagonal 131° to 35°
- Lens Mount: Ø 14
- Iris Type: Fixed
- Aperture: F1.6
|
| DORI | - 2.8 to 12 mm: D: 97-290 m, O: 38-115 m, R: 19-58 m, I: 9-29 m
|
| Illuminator | - Supplemental Light Type: IR
- Smart Supplemental Lighting: Yes
- IR Wavelength: 850 nm
- IR Range: Up to 131 ft (40 m)
|
| Video | - Max. Resolution: 3840 × 2160
- Main Stream:
- 50 Hz: 20 fps (3840 × 2160), 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 20 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream:
- 50 Hz: 25 fps (640 × 480, 640 × 360)
- 60 Hz: 30 fps (640 × 480, 640 × 360)
- Third Stream*:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- *Supported under certain settings
- Video Compression:
- Main stream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: MJPEG / H.264 / H.265
- Third stream: H.264 / H.265*
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR / VBR
- SVC: H.264 and H.265 encoding
- ROI: 1 fixed region for main stream and sub-stream
|
| Audio | - Compression: G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
- Bit Rate:
- 64 Kbps (G.711)
- 16 Kbps (G.722.1 / G.726)
- 16-64 Kbps (AAC)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- Sampling Rate: 8 / 16 / 32 / 44.1 / 48 kHz
- Environmental Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, Profile G), ISAPI, SDK
- User/Host: Up to 32 users (administrator, operator, user)
- Security: HTTPS, TLS 1.1/1.2, IP filter, audit log, digest authentication, WSSE
- Network Storage: NAS (NFS, SMB/CIFS), ANR
- Web Browsers: IE 10/11, Chrome 57+, Firefox 52+
|
| Imaging | - Image Parameter Switching: Yes
- Adjustments: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- SNR: ≥ 52 dB
|
| Interface | - Ethernet: 1 RJ45 10/100 Mbps
- On-board Storage: MicroSD up to 256 GB
- Audio: 1 input / 1 output (terminal block, 3.3 Vpp)
- Alarm: 1 input, 1 output (max. 24 VDC / 24 VAC, 1 A)
- Hardware Reset: Yes
|
| Events & AI | - Motion Detection (human and vehicle classification)
- Video Tampering Alarm
- Face Detection
- Perimeter Protection: Line crossing, intrusion detection
- Human and Vehicle Target Classification
|
| General | - Linkage: FTP / memory card / NAS upload, notify center, record, capture, email
- Material: Metal (upper cover & base), plastic dome
- Dimensions: Ø 153.3 × 111.6 mm
- Weight: Approx. 855 g
- Operating Conditions: -22° to 140°F (-30° to 60°C), ≤95% humidity
- Firmware Version: V5.5.113
- Power Supply: 12 VDC ±25%, PoE 802.3af Class 3
- Max Power Consumption: 12.5 W
- General Functions: Anti-flicker, heartbeat, password reset via email, pixel counter
- Protection: IP67, IK10
|
