| Camera | - Image Sensor: 1/3' Progressive Scan CMOS
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC on), 0 Lux with IR on
- Shutter Speed: 1/3 to 1/100,000 sec.
- Slow Shutter: Yes
- P/N: P/N
- Wide Dynamic Range: 120 dB
- Day & Night: ICR Cut
- Angle Adjustment: Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355°
|
| Lens | - Lens Type & FOV: 2.8 to 12 mm: Horizontal 95.8° to 29.2°, Vertical 50.6° to 16.4°, Diagonal 114.6° to 33.4°
- Aperture: F1.6
- Lens Mount: Ø 14
|
| DORI | - 2.8 to 12 mm: D: 64 m to 200 m, O: 25.4 m to 79.4 m, R: 12.8 m to 40 m, I: 6.4 m to 20 m
|
| Illuminator | - IR Range: Up to 131 ft (40 m)
- Wavelength: 850 nm
|
| Video | - Max. Resolution: 2688 × 1520
- Main Stream:
- 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream:
- 50 Hz: 25 fps (640 × 480, 640 × 360)
- 60 Hz: 30 fps (640 × 480, 640 × 360)
- Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Video Compression:
- Main stream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: MJPEG / H.264 / H.265
- Third stream: H.264 / H.265
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- H.264+: Main Stream
- H.265+: Main Stream
- Bit Rate Control: CBR / VBR
- SVC: Yes
- ROI: 1 fixed region for main stream and sub-stream
|
| Audio | - Environmental Noise Filtering: Yes
- Sampling Rate: 8 / 16 / 32 / 44.1 / 48 kHz
- Compression: G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
- Bit Rate:
- 64 Kbps (G.711)
- 16 Kbps (G.722.1 / G.726)
- 16-64 Kbps (AAC)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
|
| Network | - Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, Profile G), ISAPI, SDK
- Protocols: TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE
- User/Host: Up to 32 users (administrator, operator, user)
- Security: HTTPS, TLS 1.1/1.2, IP filter, audit log, digest auth, WSSE
- Storage: MicroSD / SDHC / SDXC (up to 256 GB), NAS (NFS, SMB/CIFS), ANR
- Web Browser: IE 10/11, Chrome 57+, Firefox 52+
|
| Imaging | - Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- Image Parameters Switch: Yes
- Adjustments: Rotate, mirror, privacy masks, saturation, brightness, contrast, sharpness, gain, white balance
|
| Interface | - Audio In/Out: 1 input (3.3 vpp), 1 output (3.3 vpp)
- Alarm: 1 input, 1 output (max. 12 VDC, 30 mA)
- On-board Storage: MicroSD up to 256 GB
- Hardware Reset: Yes
- Communication: 1 RJ45 10/100 Mbps
|
| Events & AI | - Motion Detection (human/vehicle classification)
- Video Tampering Alarm
- Face Detection
- Perimeter Protection: Line crossing, intrusion detection
- Human and Vehicle Target Classification
|
| General | - Linkage: FTP / memory card / NAS upload, notify center, record, capture, email
- Languages: 33 supported languages
- Functions: Anti-flicker, heartbeat, password reset via e-mail, pixel counter
- Operating Conditions: -22° to 140°F (-30° to 60°C), ≤95% humidity
- Power Supply: 12 VDC ±25%, PoE 802.3af Class 3
- Power Consumption: Max. 12.5 W
- Material: Metal (cover & base), plastic bubble
- Dimensions: Ø 153.3 × 111.6 mm
- Weight: Approx. 880 g
- Protection: IP67, IK10
|
