| Camera |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 3840 × 2160 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | - Pan: 0° to 360°
- Tilt: 0° to 75°
- Rotate: 0° to 360°
|
| Lens |
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV | - 2.8 mm: horizontal FOV 108.8°, vertical FOV 56.4°, diagonal FOV 134.3°
- 4 mm: horizontal FOV 93.3°, vertical FOV 47.2°, diagonal FOV 114.2°
|
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | - 2.8 mm: 3.3 m to ∞
- 4 mm: 3.8 m to ∞
|
| DORI |
| DORI | - 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m
- 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m
|
| Illuminator |
| Supplement Light Type | White Light, IR |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | - 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
| Sub-Stream | - 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
| Third Stream | - 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- *Third stream is supported under certain settings
|
| Video Compression | - Main stream: H.265/H.264/H.264+/H.265+
- Sub-stream: H.265/H.264/MJPEG
- Third stream: H.265/H.264
- *Third stream is supported under certain settings
|
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream |
| Audio |
| Audio Type | Mono sound |
| Audio Bit Rate | - 64 Kbps (G.711ulaw/G.711alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 16-64 Kbps (AAC-LC)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
|
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Network |
| Protocols | - TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP
- SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
- WebSocket, WebSockets, SRTP, SFTP
|
| Simultaneous Live View | Up to 6 connections at the same time |
| API | ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host | - Up to 32 users
- 3 user levels: administrator, operator, and user
|
| Security | - Password protection, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5)
- Watermark, IP filter, HTTP/HTTPS authentication
- RTP/RTSP over HTTPS, TLS 1.1/1.2/1.3
- Host authentication (MAC address)
|
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Client | NVMSV3, LTS Connect, X-VMS |
| Web Browser | - Plug-in free: Chrome 80+, Firefox 80+, Edge 89+
- Localservice: Chrome 80+, Firefox 80+, Edge 89+
|
| Image |
| Image Parameters Switch | Yes |
| Image Settings | - Rotate, saturation, brightness, contrast, sharpness, gain, white balance
- Adjustable via client software or web browser
|
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR, Distortion Correction, Defog |
| SNR | ≥ 52 dB |
| Wide Dynamic Range (WDR) | 130 dB |
| Image Stabilization | EIS |
| Privacy Mask | 4 programmable polygon privacy masks |
| Interface |
| Ethernet Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| On-Board Storage | microSD/microSDHC/microSDXC up to 512 GB |
| Built-in Microphone | |
| Reset Key | Yes |
| Event |
| Basic Event | - Motion detection (human & vehicle classification)
- Video tampering alarm
- Exception
|
| Smart Event | Scene change detection |
| Linkage | - Upload to FTP/NAS/memory card
- Notify surveillance center
- Trigger recording
- Trigger capture
- Send email
|
| Deep Learning Function |
| Face Capture | Yes |
| Perimeter Protection | - Line crossing
- Intrusion
- Region entrance
- Region exiting
- Human and vehicle classification
|
| General |
| Power | - 12 VDC ±25%, 0.7 A, max. 8.5 W
- PoE: IEEE 802.3af, Class 3, max. 11 W
|
| Material | Cover: Metal, main body: Metal |
| Dimension | Ø138.3 mm × 115.4 mm |
| Weight | Approx. 750 g |
| Operating Conditions | -30 °C to 60 °C, humidity ≤95% |
| General Function | Heartbeat, mirror, flash log, password reset, pixel counter, anti-banding |
| Language | 33 languages supported |
| Approval |
| EMC | CE-EMC, RCM, IC, KC standards |
| Safety | CB, CE-LVD |
| Environment | CE-RoHS (2011/65/EU) |
| Protection | IP67 (IEC 60529-2013) |
| Anti-Corrosion | NEMA 4X (NEMA 250-2018) |
