| Camera |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Lens |
| Lens Type | Fixed focal lens, 2.8 mm optional |
| Focal Length & FOV | 2.8 mm, horizontal FOV 111.1°, vertical FOV 57.6°, diagonal FOV 138.5° |
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | 2.8 mm: 2.5 m to ∞ |
| DORI |
| DORI (2.8 mm) | D: 61 m, O: 24 m, R: 12 m, I: 6 m |
| Illuminator |
| Supplement Light Type | White Light |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | - 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
|
| Sub-Stream | - 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
| Third Stream | - 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- *Supported under certain settings
|
| Video Compression | Main: H.265/H.264/H.264+/H.265+; Sub: H.265/H.264/MJPEG; Third: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline / Main / High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| SVC | H.264 and H.265 encoding |
| ROI | 1 fixed region for main stream |
| Audio |
| Audio Type | Mono sound |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711) / 16 Kbps (G.722.1/G.726) / 32-192 Kbps (MP2L2) / 8-320 Kbps (MP3) / 16-64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8/16/32/48 kHz |
| Environment Noise Filtering | Yes |
| Network |
| Protocols | TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP, IPv4/IPv6, SSL/TLS, SNMP, SRTP, SFTP and more |
| Simultaneous Live View | Up to 6 connections |
| API | ONVIF (Profile S/G/T), ISAPI, SDK, ISUP |
| User/Host | Up to 32 users (administrator/operator/user) |
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Client | LTS Connect, NVMS V3, X-VMS |
| Web Browser | Chrome 80+, Firefox 80+, Edge 89+ |
| Image |
| Image Parameters Switch | Yes |
| Image Settings | Rotate, saturation, brightness, contrast, sharpness, gain, white balance |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR, Distortion Correction, Defog |
| SNR | ≥ 52 dB |
| WDR | 130 dB |
| Image Stabilization | EIS |
| Privacy Mask | 4 programmable polygon masks |
| Interface |
| Ethernet Interface | 1 RJ45 10/100 M self-adaptive port |
| On-Board Storage | microSD/microSDHC/microSDXC up to 512 GB |
| Built-in Speaker | Max. 2 W, 110 dB (10 cm) |
| Built-in Microphone | Arrayed dual-microphone |
| Audio I/O | 1 line in / 1 line out (terminal block) |
| Alarm | 1 input, 1 output (24 VDC/24 VAC, 1 A) |
| Reset Key | Yes |
| Events |
| Basic Event | Motion detection (human/vehicle), video tampering, exception |
| Smart Event | Scene change detection |
| Linkage | FTP/NAS upload, email, alarm output, recording, capture, audible warning, strobe light |
| Face Capture | Yes |
| Perimeter Protection | Line crossing, intrusion, region entrance/exiting (human & vehicle) |
| General |
| Power | 12 VDC ±25%, 1.29 A (max. 15.5 W); PoE IEEE 802.3at, Class 4 (max. 17 W) |
| Material | Metal cover and body |
| Dimensions | Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5") |
| Weight | Approx. 820 g (1.8 lb.) |
| Storage/Operating Conditions | -30 °C to 60 °C, humidity ≤ 95% (non-condensing) |
| General Function | Heartbeat, mirror, flash log, password reset, pixel counter, anti-banding |
| Language | 33 languages supported |
| Flashing Light | Red and Blue Light |
| Protection | IP67, NEMA 4X |
