| Camera | - Image Sensor: 1/1.8" Progressive Scan CMOS
- Max. Resolution: 3840 × 2160
- Min. Illumination:
- Color: 0.0008 Lux @ F1.0 (AGC on)
- 0 Lux with supplemental light
- Shutter Speed: 1/3 to 1/100,000 sec.
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-75°, Rotate 0°-360°
|
| Lens | - Lens Type: Fixed focal lens, 2.8 mm
- Focal Length & FOV: 2.8 mm - Horizontal 108.8°, Vertical 56.4°, Diagonal 134.3°
- Lens Mount: M16
- Iris Type: Fixed
- Aperture: F1.0
- Depth of Field: 3.3 m to ∞
- DORI (Approx.): D 89 m (290 ft), O 35 m (115 ft), R 17 m (55 ft), I 8 m (26 ft)
|
| Supplemental Lighting | - Type: IR, Blue and Red Light
- Range: Up to 100 ft
- Technology: Yes
- IR Wavelength: 850 nm
|
| Video | - Mainstream (60 Hz):
- 24 fps (3840 × 2160)
- 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream (60 Hz): 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream (60 Hz):
- 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Supported under certain settings
- Video Compression:
- Mainstream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: H.264 / H.265 / MJPEG
- Third stream: H.264 / H.265
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline, Main, High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- SVC: H.264 / H.265 encoding
- ROI: 1 fixed region for mainstream and sub-stream
|
| Audio | - Audio Compressions: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
- Audio Type: Mono
- Audio Bit Rates:
- 64 Kbps (G.711 ulaw / alaw)
- 16 Kbps (G.722.1 / G.726)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- 16-64 Kbps (AAC-LC)
- Audio Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Environmental Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, SRTP, SFTP
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, G, T), ISAPI, SDK
- User / Host: Up to 32 users (administrator, operator, user)
- Security: Password protection, HTTPS, 802.1X (EAP-TLS / LEAP / MD5), watermark, IP filter, TLS 1.1 / 1.2 / 1.3, MAC authentication, audit log
- Network Storage: NAS (NFS / SMB / CIFS), ANR
- Client: NVMS V3, X-VMS, LTS Connect
- Web Browsers: IE 10 / 11 (plug-in), Chrome 57+, Firefox 52+, Edge 89+
|
| Image | - Image Parameters Switch: Yes
- Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
- Day / Night Switching: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR, Defog
- SNR: ≥ 52 dB
- WDR: 130 dB
- Privacy Mask: 4 programmable polygon masks
|
| Interfaces | - Ethernet Interface: 1 × RJ45, 10/100 Mbps self-adaptive
- On-Board Storage: MicroSD / SDHC / SDXC up to 512 GB
- Built-in Microphones: 1
- Built-in Speakers: 1 (Max 1.2 W, 95 dB @ 10 cm)
- Audio I/O:
- 1 input (line in), max 3.3 Vpp, 4.7 KΩ
- 1 output (line out), max 3.3 Vpp, 100 Ω
- Alarm: 1 input, 1 output (max 24 V DC / 24 V AC, 1 A)
- Reset Key: Yes
|
| Events | - Basic: Motion detection (human & vehicle), video tampering alarm, exception
- Smart: Scene change detection
- VCA: Face Capture
- Perimeter Protection: Line crossing, intrusion, region entrance, region exiting (human & vehicle)
- Linkage: FTP / NAS / memory card upload, notify center, email, alarm output, recording, capture, audible warning, strobe light
|
| General | - Power: 12 V DC ±25%, 0.75 A, max. 9 W; PoE 802.3af Class 3, max. 10.5 W
- Material: Metal cover and body
- Dimensions: Ø5.4 × 4.5"
- Shipping Dimensions: 6.7 × 6.7 × 6.3"
- Weight: Approx. 1.8 lb.
- Shipping Weight: Approx. 2.9 lb.
- Operating / Storage Conditions: -22° to 140° F (-30° to 60° C), ≤95% humidity
- General Functions: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
|
| Certifications | - Protection Rating: IP67 (IEC 60529-2013)
|
