| Camera | - Image Sensor: 1/1.8" Progressive Scan CMOS
- Max. Resolution: 3840 × 2160
- Min. Illumination: 0.0008 Lux @ F1.0 (AGC on); 0 Lux with light
- Shutter Speed: 1/3 to 1/100,000 sec.
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-75°, Rotate 0°-360°
|
| Lens | - Lens Type: Fixed focal lens
- Focal Length & FOV: 2.8 mm - Horizontal 108.8°, Vertical 56.4°, Diagonal 134.3°
- Lens Mount: M16
- Iris Type: Fixed
- Aperture: F1.0
- Depth of Field: 3.3 m to ∞
- DORI (Approx.): D 89 m (290 ft), O 35 m (115 ft), R 17 m (55 ft), I 8 m (25 ft)
|
| Supplemental Lighting | - Type: IR, White Light
- Range: Up to 40 m
- Technology: Smart
- IR Wavelength: 850 nm
|
| Video | - Main Stream:
- 24 fps (3840 × 2160)
- 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream:
- 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Supported under certain settings
- Video Compression:
- Main stream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: H.264 / H.265 / MJPEG
- Third stream: H.264 / H.265
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline, Main, High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- SVC: H.264 and H.265 encoding
- ROI: 1 fixed region for main stream and sub-stream
|
| Audio | - Audio Compression: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
- Audio Bit Rate:
- 64 Kbps (G.711 ulaw / alaw)
- 16 Kbps (G.722.1 / G.726)
- 16-64 Kbps (AAC-LC)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- Audio Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Environment Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, SRTP, SFTP
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP
- User / Host: Up to 32 users (Administrator, operator, user)
- Security: Password protection, HTTPS, 802.1X (EAP-TLS / LEAP / MD5), watermark, IP filter, TLS 1.1 / 1.2 / 1.3, MAC authentication, audit log
- Network Storage: NAS (NFS / SMB / CIFS), ANR
- Clients: LTS Connect, NVMS, X-VMS
- Web Browsers: IE 10/11 (plug-in), Chrome 57+, Firefox 52+, Edge 89+
|
| Image | - Image Parameter Switching: Yes
- Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
- Day / Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- SNR: ≥ 52 dB
- WDR: 130 dB
- Privacy Mask: 4 programmable polygon masks
|
| Interface | - Ethernet Interface: 1 × RJ45, 10/100 Mbps self-adaptive
- On-Board Storage: MicroSD / SDHC / SDXC up to 512 GB
- Built-in Microphone: Yes
- Reset Key: Yes
|
| Events | - Basic: Motion detection (human & vehicle classification), video tampering alarm, exceptions
- Smart: Line crossing, intrusion, region entrance / exiting, scene change detection
- Face Capture: Yes
- Linkage: FTP / NAS / memory card upload, notify center, recording, capture, email
|
| General | - Power: 12 V DC ±25%, 0.54 A, max. 6.5 W; PoE 802.3af Class 3, max. 8 W
- Material: Metal cover and body
- Dimensions: Ø5.4 × 4.5"
- Shipping Dimensions: 6.7 × 6.7 × 6.3"
- Weight: Approx. 1.7 lb.
- Shipping Weight: Approx. 2.3 lb.
- Operating & Storage Conditions: -22° to 140° F, ≤95% humidity
- General Functions: Heartbeat, mirror, password reset via email, pixel counter, anti-banding
|
| Certifications | - EMC: CE-EMC, RCM, IC, KC
- Safety: UL 62368-1, CB (IEC 62368-1), CE-LVD, BIS
- Environmental: CE-RoHS
- Protection: IP67 (IEC 60529-2013)
|
