| Camera | - Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2688 × 1520
- Min. Illumination:
- Color: 0.001 Lux @ F1.0, AGC on
- 0 Lux with light
- Shutter Speed: 1/12 to 1/100,000 sec.
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-75°, Rotate 0°-360°
|
| Lens | - Lens Type: Fixed focal lens
- Focal Length & FOV: 2.8 mm - Horizontal 100.2°, Vertical 54.7°, Diagonal 119.7°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.0
- Depth of Field: 1.9 m to ∞
- DORI (Approx.): D 63 m (205 ft), O 25 m (80 ft), R 12 m (40 ft), I 6 m (20 ft)
|
| Supplemental Lighting | - Type: IR, White Light
- Range: Up to 100 ft
- Technology: Smart
- IR Wavelength: 850 nm
|
| Video | - Mainstream:
- 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Supported under certain settings
- Video Compression:
- Mainstream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: H.264 / H.265 / MJPEG
- Third stream: H.264 / H.265
- Video Bit Rate: 256 Kbps to 8 Mbps
- H.264 Type: Baseline, Main, High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- SVC: H.264 and H.265 encoding
- ROI: 1 fixed region for mainstream and sub-stream
|
| Audio | - Audio Type: Mono
- Audio Compression: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
- Audio Bit Rate:
- 64 Kbps (G.711 ulaw / alaw)
- 16 Kbps (G.722.1 / G.726)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- 16-64 Kbps (AAC-LC)
- Audio Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Environmental Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, SRTP, SFTP
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP
- User / Host: Up to 32 users (administrator, operator, user)
- Security: Password protection, HTTPS, 802.1X (EAP-TLS / LEAP / MD5), watermark, IP filter, TLS 1.1 / 1.2 / 1.3, MAC authentication, audit log
- Network Storage: NAS (NFS / SMB / CIFS), ANR
- Client: NVMS V3, X-VMS, LTS Connect
|
| Image | - Image Parameter Switch: Yes
- Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
- Day / Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR, Defog
- SNR: ≥ 52 dB
- WDR: 130 dB
- Privacy Mask: 4 programmable polygon masks
|
| Interface | - Ethernet Interface: 1 RJ45 10/100 M self-adaptive port
- On-Board Storage: microSD / microSDHC / microSDXC up to 512 GB
- Built-in Microphones: 1
- Built-in Speakers: 1 (Max. 1.2 W, 95 dB @ 10 cm)
- Audio I/O:
- 1 line in (3.3 Vpp, 4.7 KΩ, non-equilibrium)
- 1 line out (3.3 Vpp, 100 Ω, non-equilibrium)
- Alarm: 1 input, 1 output (max. 24 V DC / AC, 1 A)
- Reset Key: Yes
|
| Events | - Basic: Motion detection (human & vehicle classification), video tampering alarm, exception
- Smart: Scene-change detection
- Perimeter Protection: Line crossing, intrusion, region entrance, region exiting (human & vehicle classification)
- Face Capture: Yes
- Linkage: FTP / NAS / memory card upload, notify center, email, alarm output, recording, capture, audible warning, flashing light
|
| General | - Power: 12 V DC ±25%, 0.75 A, max. 9 W; PoE 802.3af, Class 3, max. 10.5 W
- Material: Metal cover and body
- Dimensions: Ø138.3 × 115.4 mm (Ø5.4 × 4.5")
- Shipping Dimensions: 170 × 170 × 160 mm (6.7 × 6.7 × 6.3")
- Weight: Approx. 820 g (1.8 lb.)
- Shipping Weight: Approx. 1,316 g (2.9 lb.)
- Operating Conditions: -30°C to 60°C, ≤95% humidity
- General Functions: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
- Flashing Light: Red and Blue Light
|
| Certifications | - Protection Rating: IP67 (IEC 60529-2013)
|
